Fully automatic cereal bar packing machine
As drawing, the line is combined by 4 parts:
This automatically packaging line connects with the Cooling conveyer, used to distributing, sorting and automatically packaging. Automatically control the start, stop and speed according to the state of product, completely free of manual control. Request the machinery with high stability and concordant.
This automatically packaging line includes 4 parts:
A: The pulling distance system B: The crossing transitional system C: The automatic sorting and feeding system (with turntable) D: ZP500 packing machine.
A,Distance Pulling conveyor (2 sets) part:
This part of the conveyor the series of products are divided into two parts: Each part through the three sections of one meter long conveyor, Pull from the parse conveyor conveyor speed change gradually, Through the speed difference between baffle and arrangement the column cake arrangement for three single row, namely six single row.
This part with accurate, ensure variable column guarantee from plugging material, avoid artificial intervention, continuous.
And through the platform of damper array device make through the cake with a orderly direction into two columns on delivery. In order to achieve effective, uninterrupted, cake spacing equal transfer effect.
B,Horizontal transverse system (2 set) part:
One row Cereal Bar directly into an automatic feeding machine, another cake sent to another automatic feeding machine is composed of a transverse conveyor.
C,Automatic feeding unit (with steering) (2sets) part :
The part of feeding conveyor front sections has steering function, through the horizontal conveyor belt and the vertical convening’s different speed, the material can be in its position take turn by 90 degrees or forward conveyed orderly.
Automatic feeding part has the buffer storage function, avoid packaging machine stop for times. Automatic packaging machine’s speed and position each match itself, ensure the packaging position is accurate when the cake into the package machine, corresponding speed. The machine will stop automatically then the cake is insufficient, automatic starting packing again when cake is incoming, free manual.
Automatic feeding part structure performance advantages: humanization design, simple structure, convenient operation, convenient cleaning disinfection, no sanitation dead; conveyor belt with automatic alignment function (exemption regulation), conveyor belt can be quickly dismounting.
D,Horizontal packing machine(2sets)system:
The system is combined by 2sets horizontal packing machine; The packing machines installed with date printer. For easy operation, each machine with the double paper support rolls.
3),FEEDING PACKING SYSTEM MATERIAL:
A,The feeding and packing system convey plant, push block, or the parts directly touch with the food, all made of SS SUS304;
B,The feeding and packing system frame surface and driving parts, is Carbon steel,Nickel,AL;
C,The convey belts are PU food level;
D,The feeding system photocell eyes is the Germany SICK brand;
E,The transducer is Germany Schneider brand;
F,The encoder is Japan OMRON brand.
