Specifications
1.Suitable for different size of container2.Easy to operate
3.Function well
4.High efficiency,quality
Bucket making machine
Automatic paint bucket tin can making machines/bucket making equipment
1.Main technical data.
Model |
FH18-90ZD |
Linear rate of welding |
6-36m/min |
Production capacity |
20~45cans/min |
Applicable can diameter |
220~300mm |
Applicable can height |
250~280mm |
Applicable material |
Tinplate T2.5~DR8 |
Material thickness |
0.18~0.32mm |
Seam welding landing |
0.4mm |
Seam point distance |
0.5~0.8mm |
Copper wire diameter |
1.38mm |
Cooling water |
Temperature 12~18°C |
Pressure:0.5Mpa | |
Discharge 10L/min | |
Air consumption |
Pressure 0.7Mpa |
Discharge 600L/min | |
Power |
380V±5% 50Hz |
Total power |
18KVA |
Dimension |
2100x1500x1900mm |
Weight |
2000kg |
2.Latest picture
***************************************accessories*********************************************************
3.Our major component suppliers
1, PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.
2, Low voltage apparatus are produced by SCHNEIDER.
3, IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.
4,OMRON is our sensor supplier.
5, HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.
4.Can making technology process
Cutting-----rounding-----welding-----coating-----drying-----pre-curling and expanding-----flanging-----seaming bottom-----beading and curling
