Specifications
Complete orange juice production line1.Fruit juice ,orange juice,mango juice
2.pet /glass bottle.
Complete orange juice production line
Commercially Available Orange Juice Categories:
Orange Processing Equipment
Fruit Sorter
This machine is ideal for sorting of various fruits and vegetables. It is completely made of food grade stainless steel. The rolling lever parts are made of special shout shaft stainless steel chain and stainless steel polished seamless steel tubes. Its light construction make it the best among all fruit sorters available in the market. It is customizable according to customer's requirements.
Spiral Juice Extractor
This machine is ideal for various fruits and vegetables juice extraction. It is commonly used for juicing pineapple, tomato, apple, orange, etc.
Technical Parameters:
Complete orange juice production line
I. Characteristics:
Complete orange juice production line -----introduction
1.The Complete orange juice production line is mainly used for bottling juice ,such as apple juice ,mango juice,orange juice,and other fruit juice.It can also be used for bottling water ,such as pure water and mineral water.
2.The Complete orange juice production line includes washing part ,filling part,and sealing part,all of the process is automatic.
3. The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automaticly,
4. Complete orange juice production line is convenient to operate with higher auromation because everypart of the machine is inspected to run with photo electicity.
5. Complete orange juice production line can be produced acoording to your requiements,because we are professional beverage processing manufacture.
II. Main Models and technical parameters
Model |
RCGF18-18-6 |
RCGF24-24-8 |
RCGF32-32-12 |
RCGF40-40-12 |
RCGF50-50-15 |
Production Capacity:500ml(B/h) |
5000 |
8000 |
12000 |
15000 |
18000 |
Suitable Bottle Types(mm): |
Round or square square shaped bottle |
||||
PET Bottle Dimension: (mm) |
Bottle diameter:50-110 Height :150-330mm |
||||
Suitable Cap Standard: |
plastic screw Cap |
||||
Filling Pressure(Mpa) |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
Rinsing Precision:(Mpa) |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
Installed Capacity:(L) |
4 |
4.8 |
7.6 |
8.3 |
9.6 |
Overall Size(mm)(L×W×H) |
2650x1900x2400 |
2900×2100×2400 |
4100×2400×2400 |
4550×2650×2400 |
5450x3210x2400 |
Total Weight: (kg) |
2800 |
3500 |
4200 |
5600 |
6500 |
