Leaf filter is used for kinds of rude oil,degumming,decolorizing oil and biodiesel.Leaf Filter
Usage of leaf filter:
Oils and fats industry: filter crude pressed oil, bleaching oil, hydrogenation oil, wintering oil, etc.
Food industry: filter sugar solutions such as granulated sugar, grape sugar, etc, to separate out bleaching agent of active carbon, filter beer, fruit juice, wort, alcohol, drinking for clarification.
Chemical industry: for separating out all kinds of crystals, catalysts, bleaching agents of active carbons in petroleum industry, inorganic chemical industry and organic chemical industry.
Features and benefits:
pact structure, small occupying area.
2.high fineness filtrate, low consumption and losses, high economic efficiency.
3.high fineness filtrate, low consumption and losses, high economic efficiency.
4.since hermetic and continuous production can be realized by connecting two filters in parallel and operating them alternately, it is high efficiency.
Main models and specifications
Type |
Filtering area |
Capacity (T/h.m²) |
Working pressure(Mpa) |
Working temperature |
Volume for filtering cylinder |
weight (kg) |
||
Edible oil |
drink |
normal |
Max |
|||||
6YT-2 |
2.5 |
0.4-0.6 |
1-3 |
0.1-0.4 |
0.6 |
≤150 |
120 |
300 |
6YT -4 |
4 |
0.5-1.2 |
2-5 |
250 |
400 |
|||
6YT -7 |
7 |
1-1.8 |
4-7 |
420 |
600 |
|||
6YT -10 |
10 |
1.6-3 |
6-9 |
800 |
900 |
|||
6YT -12 |
12 |
2-4 |
8-11 |
1000 |
1100 |
|||
6YT -15 |
15 |
3-5 |
10-13 |
1300 |
1300 |
|||
6YT -20 |
20 |
4-6 |
12-17 |
1680 |
1700 |
|||
6YT -25 |
25 |
5-7 |
16-21 |
1900 |
2000 |
|||
6YT -30 |
30 |
6-8 |
19-25 |
2300 |
2500 |
|||
6YT -36 |
36 |
7-9 |
23-31 |
2650 |
3000 |
|||
6YT -45 |
45 |
8-11 |
30-38 |
3200 |
3500 |
|||
6YT -52 |
52 |
9-13 |
36-44 |
3800 |
4000 |
|||
6YT -60 |
60 |
10-15 |
42-51 |
4500 |
4500 |
|||
6YT -70 |
70 |
11-17 |
48-60 |
5800 |
5500 |
|||
6YT -80 |
80 |
12-19 |
56-68 |
5860 |
6000 |
|||
6YT -90 |
90 |
13-21 |
64-78 |
6700 |
|
|||
Note: The machine requires to match with one air compressor to drive the filter to work.
