Meanwell Brand Dimmable Power Supply 24V 185W Dimmable HLG-185H-24B

Meanwell Brand Dimmable Power Supply 24V 185W Dimmable HLG-185H-24B thumbnail-1
Meanwell Brand Dimmable Power Supply 24V 185W Dimmable HLG-185H-24B photo-1
US$ 1 - 49 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Meanwell Brand
Model Number:
HLG-185H-24B
Contact Supplier Request Quote Chat Now
Shenzhen Simonlighter Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Meanwell Brand
Model Number HLG-185H-24B
Output Power Other, 180w led driver 24v 180w dimmable
Output Type Single
Input Voltage 220V
Output Voltage DC24V
Output Frequency 50-60
Output Current 0-7.8A



Meanwell Brand Dimmable Power supply 24V 185W dimmable HLG-185H-24B



Meanwell Brand Dimmable Power supply 24V 185W dimmable HLG-185H-24B



Features :

  • Universal AC input / Full range (up to 305VAC)
  • Built-in active PFC function
  • High efficiency up to 94%
  • Protections: Short circuit /Over current /Over voltage /Over temperature
  • Cooling by free air convection
  • OCP point adjustable through output cabel or internal potentiometer
  • IP65 design for indoor or outdoor installations
  • Three in one dimming function(1~10Vdc or PWM signal or resistance)
  • Suitable for LED lighting and street lighting applications
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry / damp / wet locations
  • 5 years warranty


Meanwell Brand Dimmable Power supply 24V 185W dimmable HLG-185H-24B

MODEL:  MEAN WELL  led driver 24v dimmable

HLG-185H-24B

OUTPUT

DC VOLTAGE

24V

CONSTANT CURRENT REGION

12 ~ 24V

RATED CURRENT

7.8A

RATED POWER

187.2W

RIPPLE & NOISE (max.)

150mVp-p

VOLTAGE ADJ.RANGE

22 ~ 27V

CURRENT ADJ.RANGE

Can be adjusted by internal potential meter .or through output cable

3.9 ~ 7.8A

VOLTAGE TOLERANCE

0.01

LINE REGULATION

0.005

LOAD REGULATION

0.005

SETUP, RISE TIME

2500ms, 80ms at full load 230VAC / 115VAC ; B type 2500ms,

200ms at 95% load 230VAC / 115VAC

HOLD UP TIME (Typ.)

16ms at full load 230VAC / 115VAC

INPUT

VOLTAGE RANGE

90 ~ 305VAC 127 ~ 431VDC

FREQUENCY RANGE

47 ~ 63Hz

POWER FACT.or

PF 0.95/230VAC PF 0.98/115VAC at full load and rated output

voltage PF 0.9 at 50 ~ 100%  load

EFFICIENCY (Typ.)

93.5%

AC CURRENT (Typ.)

12V

1.8A / 115VAC 0.8A / 230VAC 0.7A / 277VAC

INRUSH CURRENT (Typ.)

15V ~ 54V

2.1A / 115VAC 0.9A / 230VAC 0.8A / 277VAC



COLD START 75A/230VAC

LEAKAGE CURRENT

<0.75mA / 277VAC m

ENVIROMENT

WORKING TEMP.

  -40C ~ +80C

OTHERS

MTBF

192.2K hrs min.

DIMENSION

228*68*38.8mm  (L*W*H)

PACKING

1.15Kg; 12pcs/14.8Kg/0.8CUFT
