Home > Consumer Electronics > LED Display > Indoor LED Display > LAMP Flexible Led Curtain Display

LAMP Flexible Led Curtain Display

Name: LAMP Flexible Led Curtain Display
Brand: LAMP
SKU: 107760057

LAMP Flexible Led Curtain Display thumbnail-1

LAMP Flexible Led Curtain Display photo-1

US$ 1 - 8,000 MOQ: 1 Square Meter

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

LAMP

Usage:

Outdoor

Contact Supplier Request Quote Chat Now

Shenzhen Lamp Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Hong Kong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name LAMP

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 18.75mm,40mm

Screen Dimension According to client's require

Specifications

flexible led curtain
1) fast installation
2) see throught effect
3) solid reliability
4) perfect for background application

flexible led curtain

features:

1, easy hanging structure support fast installation.

2, 14-bit color processing enable a vivid color quality.

3, built-in power supply and controller enable system reliability.

4, wide product range meet all your need to creat a unique background.

5, total solution includes video processor, rental power distribution unit, truss...etc.

LED Curtain display specification:

Pixel Pitch:	18.75 mm	40 mm
Brightness:	5000 cd/sqm	2000 cd/sqm
LED Configuration:	SMD 3 in 1	1R1G1B
Pixel Density:	2844 pixels/sqm	625 pixels/sqm
Viewing Angle(Vertical):	140°	120°
Viewing Angle(Horizontal):	140°	60°
Cabinet Resolution:	32*32 pixels	16*32 pixels
LED Lifetime:	100,000 hours	100,000 hours
Power Consumption(Maximum):	700 W/sqm	150 W/sqm
Weight:	8 kg/unit	8.5 kg/unit
Processing:	12 bit	12 bit
Refresh Rate:	1500Hz	600Hz
Rotation Angle:	-15° to +15°	-20° to +20°
Material:	Aluminum alloy	Aluminum alloy
Temperature Range(Operating):	-20 to 60 Degrees Celsius	-10 to 40 Degrees Celsius
Humidity Range(Operating):	10% to 99%	10% to 99%
Protection Rating:	IP 65	IP 65
Dimension(WHD):	60060091 mm	640128091 mm
LED Processor	LINSN	LINSN
Signal:	DVI up to UXGA, SDI, HD-SDI, S-video, compositem, YUV

Features of 18.75mm

As a modular system of LED video panels which designed for the demanding rental and staging market & fixed installations, seele allows you to create your own video imaging design to set your staging apart from the ordinary.

A true IP65 protection rating, wide operating temperature range and high brightness enable the curtain to be used in most indoor & outdoor applications.

1. ventilative module which can be rotated to and fro at the maximum of 10 degrees.

2. creative design on the connection structure which could be installed fast and easily without tools. And the assembly or disassembly of single module is applicable for any position on the display.

3. a high efficiency power supply with 83% power efficiency which saves 10% more than normal display.

4. a fan-less design to meet all the kinds of quiet occasions.

System Diagram

workshop

Shenzhen LAMP Technology co., LTD was founded on the core value of professional integrity with the ultimate goal of complete customer satisfaction. With our 20,000 square meters office dedicated to Sales & Marketing, Customer Support, R&D and Manufacturing located, now LAMP is active in more than 90 countries and employs more than 500 staff. Its service network has covered Asia, Europe, America and Africa. In 2011 LAMP posted sales of 50 million USD.

We clearly understand that people need distinct solutions when facing different applications. With our rich engineering experience and solid R&D background, after years’ efforts, we are proud to be a turn-key solution provider for your business. As with advertising, we not only provide a reliable LED display, but also B/S based structure, user-friendly professional advertising software to ultimate your investment. Concerning rental and staging, we provide you with durable, easy-setup, uniquely designed products as well as high end video processing equipment. When it comes to sports display, we provide a full range of software and hardware to play advertising, show scores and live show. For more details, Contact us today!
