Home > Consumer Electronics > LED Display > Indoor LED Display > P10.41 Led Curtain Display Fur Stage Usage

P10.41 Led Curtain Display Fur Stage Usage

Name: P10.41 Led Curtain Display Fur Stage Usage
Brand: LAMP
SKU: 107760607

P10.41 Led Curtain Display Fur Stage Usage thumbnail-1

P10.41 Led Curtain Display Fur Stage Usage photo-1

US$ 1 - 8,000 MOQ: 5 Square Meters

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

LAMP

Model Number:

P10.41 Seele series

Contact Supplier Request Quote Chat Now

Shenzhen Lamp Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name LAMP

Model Number P10.41 Seele series

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, P10.41

Screen Dimension 333mm*999mm*30mm for per cabinet

Specifications

P10.41 Led curtain display fur stage usage
1)High see through rate
2)Completely DIY cabinet design
3)Easy formation of a comp

P10.41 Led curtain display fur stage usage

Main features

1.Fast Assembly
Creative design on the connection structure which could be installed fast and easily without tools. And the assembly or disassembly of single module is applicable for any position on the display.

2.Rotated Stucture
Ventilative module which can be rotated to and fro.

3.Fan-less
A fan-less design to meet all kinds of quiet occasions.

4.High Power Efficiency
A high efficiency power supply with 83% power efficiency which saves 10% more than normal display.

Specification

Visual Parameter
Pixel Pitch:	10.41mm
Pixel Density:	9,227 pixels/sq meters
Pixel Configuration:	SMD3535
Cabinets Dimension:	33399930 mm
Cabinets Resolution:	32*96 pixels
Viewing Angle (Horizontal):	140°
Viewing Angle (Vertical):	140°
Performance Parameter
Brightness:	1,000 cd/sq meters
Max Consumption:	220W/unit
Weight:	8.6 kg/unit
Gray Scale Level:	16 bit
Refresh Rate:	1,500Hz
Rotation Angle:	-25° ~ +25°/-15° ~ +15°
Material:	Aluminum alloy
LED Lifetime:	50,000 hours
Environment Parameter
Temperature Range (Operating):	-20 ~ 60ºC
Operation Humidity:	10%~99%
Input Voltage:	90~260VAC,50/60Hz
Ingress Protection:	IP20
Control Parameter
Control System	DBSTAR
Signal:	DVI up to UXGA, SDI, HD-SDI, S-video, compositem, YUV

Pictures showing

As a modular system of LED video panels which designed for the demanding rental and staging market & fixed installations, seele allows you to create your own video imaging design to set your staging apart from the ordinary.

A true IP65 protection rating, wide operating temperature range and high brightness enable the curtain to be used in most indoor & outdoor applications. Until now, seele series includes 18mm and 40mm for outdoor application, and a 6mm is in process.

Technologies:

Currently, LAMP Tech has developed various products and solutions, some of which are unique in the global market. Besides the regular led screens such as fixed installation and rental screens, we are ahead of our competitors in the following products and solutions such as

1. EMC compliance — TUV certified screens, both in Class A and Class B;

2. ETL compliant – we passed the formality by ETL certification authority in 2009, and have been under strict inspection and supervision by such organization;

3. Finest pixel pitch led screens in the world: P1.5mm, P1.8mm, P2.0mm & P2.5mm, and has achieved great popularity and generated great sales with these unique products;

4. Finest pixel pitch and magnificent outdoor curtain screens in the world: P9 outdoor curtain screen, P10.41mm curtain screen, and so on;

5. Probably the thinnest and spectacular die-cast cabinet for indoor products with the pixel pitches of P4mm, P5mm, P6mm & P10mm, etc;

6. A completely flexible product that enables users to form a complete circle easily;

All above new and popular products, together with a lot more others yet to come, are our own proprietary products and have been developed by our most talented technical team.
