LAMP's Led Sports Board for Stadium

Name: LAMP's Led Sports Board for Stadium
Brand: LAMP
SKU: 107760945

US$ 1 - 8,000 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

LAMP

Size:

according to customer's request

Shenzhen Lamp Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Hong Kong/Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name LAMP

Size according to customer's request

Shape rectangle

Anti-wind Ability strong

Specifications

led sports board
1.Perfect image&video quality
2.High refresh rate
3.Unique structure design
4.Extreme viewing angle

led sports board

Main Features

1 High brightness and be adjustable. Built-in functional card support brightness automatically adjustment.

2 Using virtual pixel, with a better viewing effect for advertising spots.

3 a turn-key solution including professional advertising software and hardware.

4 rich stadium LED display engineering experience both in domestic and oversea market.

5 Unbeatable product stability through strict Quality Control System.

Specification

Pixel pitch (mm)	P10	P12	P16
Pixel Configuration	1R,1G,1B	1R,1G,1B	1R,1G,1B
Module Dimension (L × H ) mm*mm	160 ×160	192 × 192	256 × 128
Module Resolution (L × H) pixels*pixels	16 × 16	16 × 16	16 × 8
Cabinet Dimension (L × H×W) mm*mm	800 × 640	768 × 576	768× 768
Cabinet Resolution (L × H) pixels*pixels	80 × 64	64 × 48	48 × 48
Density (pixels / m2)	10,000	6,944	3,906
Brightness Density (>=cd/m2)	5000	5500	5500
Drive mode	1/4 scanning	1/2 scanning	static
Best Viewing distance (m)	10~200	15~200	20~200
Power consumption (Average) (w/ m2)	500	440	537
Power consumption (Max) (w/ m2)	1100	1100	1343
Viewing angle	Horizontal angle: 120 degree ; Vertical angle: 120 degree
Gray scale	16384 gray scale in each Red,Green,Blue color
Kinds of Color	68.7 billion kinds
Refresh Velocity	60 frame/sec(minimum)
Ingress protection IP	Front IP 65, Rear IP 43
Refresh Rate	600HZ(minimum)
Display Life	100,000 hours(minimum)
Display MTBF	10000 hours
Blind Pixels Rate	0.0001(minimum)
Working Voltage	AC220V±15% 47~64HZ
Effective Control Distance	100m (kind 5 cable) / 1000m or more (Optical fiber)
Operation temperature	- 20°C ~ + 60°C
Operation Humidity	10% ~ 90% RH
