30L 50L 60L 100L Beer Brewing Equipment, Brew Conical Fermenter for Brewery Fermentation Processing

30L 50L 60L 100L Beer Brewing Equipment, Brew Conical Fermenter for Brewery Fermentation Processing thumbnail-1
30L 50L 60L 100L Beer Brewing Equipment, Brew Conical Fermenter for Brewery Fermentation Processing photo-1
US$ 500 - 5,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
ZJ
Contact Supplier Request Quote Chat Now
Hangzhou Zhengjiu Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name ZJ
Model Number ZJ - B2
Voltage 240V / 220V / 380V
Power(W) 3HP
Weight 100-2000
Dimension(L*W*H) according to volumn
Processing Types liquid / alcohol
Certification CE / ISO 9001: 2008
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas



Product Description

Beer Brewing Equipment







Zhengjiu Machinery Tanks Jacketed Conical Fermentation Tanks are available from 1 Barrel to 100 Barrels.  The conical fermentation tanks have a dish top with cylindrical body.  The 60 Degree conical bottom is ideal for fermenting and improving the quality of beer as well as breeding yeast.  All tanks are food grade stainless steel 304 with a 3 mm thickness for 3BBL-70BBL, while larger tanks have a 4 mm thickness.  The cooling system is a dimple jacket withinsulated polyurathane filling.  All tanks are designed for up to 14.7 PSI and tested at 30 PSI.  The inside of the tanks are polished to Ra>.22um and the outside is a Brushed / Satin finish.

The Conical Fermenator is a beautifully designed product for the discriminating brewer. Its features provide commercial brewery functionality at a consumer good price. It is easy to use and loaded with standard features.  100% Stainless Steel. All tanks come standard with 25% head space on top of working volume.  All Cone come standard with a Racking Arm.  Rotating Racking Arm is standard equipment!! Just like the Craft Brewers huge conical fermenters. This feature allows you to start your siphon with the racking arm horizontal, and rotate it slowly downward until you just start picking up yeast sediment. Clearly the best and only way to siphon clear beer or wine!



 30L 50L 60L 100L beer brewing equipment, brew conical fermenter for brewery fermentation processing

Product information:

  • Shadowless Manway
  • Thru the Wall Spray Ball
  • CIP Lines
  • 1" Rotating Racking Arm with 1 1/2" TC Butterfly Valve
  • 2" Pull Handle Butterfly for Drain with Elbow and 12" Spool to outside wall
  • Thermometer
  • Thermowell
  • Sample Valve
  • 3mm Thickness Tanks
  • 60 Degree Conical Bottom
  • 2 extra 1 1/2" ferules on top for accessories

Dimple Jacketed, Insulated Polyurathane Filled ;







Specifications

Beer brewing vessel, Strong beer fermenters for sales 7bbl


1. 100 percent Stainless steel SUS304 or 316L construction

2. seamless weld

3. three years warranty

4. Reasonable price and reliable supplier



 30L 50L 60L 100L beer brewing equipment, brew conical fermenter for brewery fermentation processing



Company Information




DRAWING



WHY CHOOSE THE PRODUCT

1. Compare to other suppliers, we promise to spend more times on the polish and treat for the welding seam and port.

2. High Quality fitting adopted to keep long time use.

3. Best Service. From the time customer release the order till customer get the products, we will provide on-time service, and willing to solve any problem at the first time.

4. The products has one year Warranty from the time when the customer received the tanks.

5. Customer special design is available.


HANGZHOU ZHENGJIU MACHERY MANUFACTURING CO.,LTD PROMISE TO MAKE EVERY TANKS WITH BEST QUALITY AND PROVIDE BEST SERVICE FOR HONORABLE CUSTOMER







Packaging & Shipping

  1 - When Delivered by LCL (Less Container Loading), The tank will be covered by Pearl Wool, then Packed in Wooden case !



2 - When Loaded in Whole Container, The tank will be covered by Pearl Wool, Lay down & fixed on a Iron frame, finally the whole tank will be fixed in the container !



 30L 50L 60L 100L beer brewing equipment, brew conical fermenter for brewery fermentation processing



Our Services



1) we will supply and confirm you with drawing before manufacturing.

2) we manufacture the equipment according the drawings.

3) we will free to sending the fittings which has broken at accident during two years.

30L 50L 60L 100L beer brewing equipment, brew conical fermenter for brewery fermentation processing
