Specifications
storage tank1. Factory design and custom made
1) SS304 ; SS316L
2) single-layer; Double-;3-layer
3.CE&ISO9001 Certified
Stainless Steel Wine Storage tank
Zhengjiu Machinery Tank Jacketed Bright Beer Tanks are available from 1 barrel to 100 or more barrels. The Bright(Brite) tank have the dish cover at top & bottom with the Cylinder Boday. All tanks are food grade stainless steel 304 with a 3 mm thickness for 3BBL-70BBL, while larger tanks have a 4 mm thickness. The cooling system is a dimple jacket with insulated polyurathane fill. All tanks are designed for up to 14.7 PSI and tested at 30 PSI. The inside of the tanks are polished to Ra>.22um and the outside is a brushed / Satin finish. All tanks come standard with 25% head space on top of working volume.
Our Bright beer tanks are beautifully designed for the discriminating brewer and loaded with many standard features. These features provide commercial brewery functionality & consumer good price for all brewers alike. Special orders may be placed along with custom features to your specifications.
Features Include:
- Shadowless Manway
- Thru the Wall Spray Ball
- CIP Lines
- 2" Pull Handle Butterfly for Drain with Elbow and 12" Spool to outside wall
- Thermometer
- Thermowell
- Sample Valve
- 3mm Thickness Tanks
- 2 extra 1 1/2" ferules on top for accessories
- Dimple Jacketed, Insulated Polyurathane Filled ;
Optional Accessories:
- Pressure Relief/Vaccumm Valve Available
- 1" Rotating Racking Arm with 1 1/2" TC Butterfly Valve
- Carbon Stone Available
- Extra Ferules installed per ferule 1" thru 3" sizes
- Sight Level Glass with 2 valves Installed;
- Oval Manway 430mm x 330mm (550mm x 430mm) with Seal on side;
Quick Detail:
- Variable capacity tanks from 300L to 10000L
- Volume design: Properly according to the capacity requests
- Certification: CE
- Warranty: 12 months
- Thickness: 3mm
- Voltage: 220V/380V(Or to be customized)
- Condition: New
- Material: Stainless Steel AISI 304 or AISI 316
- Micro-spiral finish on the outside
- Mirror finish on the inside
- Pressure gauge with pump
- 2-way air valve on lid
FEATURE:
1 - When Delivered by LCL (Less Container Loading), The tank will be covered by Pearl Wool, then Packed in Wooden case !
2 - When Loaded in Whole Container, The tank will be covered by Pearl Wool, Lay down & fixed on a
Iron frame, finally the whole tank will be fixed in the container !
Service:
1) we will supply and confirm you with drawing before manufacturing.
2) we manufacture the equipment according the drawings.
3) we will free to sending the fittings which has broken at accident during two years.
Call or email jenny @ for pricing!
