Machines for manufacturing small coffee paper cups
DB-L12 paper cup making machine is multistation automatic machine. It has continuous automatic procedures like feeding, sealing, oil filling, washing, heating, knurling, convex knurling, curling, unloading, etc. It is ideal equipment for producing paper testing-drinking cups, market cups, advertising cups, etc. It is widely used for hot drink and some disposable cups.
Main Technical Parameter:
Model |
DB-L12 PAPER CUP MACHINE |
Cup size |
A: Top outside diameter: 50~90mm B: Height :45~115mm C: Bottom outside diameter:35~64mm D: Depth of Cup bottom: 4.5~12mm
|
Applicable Paper |
150-250gsm (one side PE coated paper) 150~380gsm (two side PE coated paper) |
Production speed |
45-55pcs/min |
Electrical requirement |
Without ultrasonic:3.8KW 380V 50Hz With ultrasonic: 8 KW 380V 50HZ |
Compressed air |
0.4m3/min ,Air source request (double PE): 0.4-0.6 Mpa |
Weight |
1300 KG |
Overall dimensions |
(L*W*H ) 2.55*1..26*1.7 M |
Certificate & Our product and workshop :
5.Full line for paper cups making:
DB-L12 machine details:
1) We choose aluminum material for turn-plate.
2)Heating head is oblate , which can seal the cups easily , it is much better than that round size.
3).We choose 3 raws of chains between the three main turn-plates&We use gear running
4).Bottom part:
8.Packing details:
