Help Center20-150ml Automatic Piston Essential Filling Machine
Related Products
-
GX2-20 Liquid Production Line (Integrated Machine,Filling Machine and Capping Machine)NegotiableMOQ: 1 Set -
Auto Bottle Oral Liquid Filling and Capping Multifunctional Production LineNegotiableMOQ: 1 Set
-
Automatic Bottle Liquid Filling and Capping LineNegotiableMOQ: 1 Set
-
Automatic Liquid Filling Line (oil, Jam, Sauce,honey,wine,shampoo, Pesticide,etc)US$ 10,000 - 100,000MOQ: 1 Set
-
CZ-10 Filler and Capper Machine (for Little Bottles)NegotiableMOQ: 1 Set
Technical performance:
The filling process is under control of PLC. All operations complete on the touching screen. It adopts the piston filling way.
It suits for liquid. filling within chemical ,daily chemical, food, cosmetic, medicine and pesticide etc, especially fitting for high-viscous materials filling.
It has simple structure, convenient operation. It is a fairly ideal and economic filling equipment for high-viscous materials filling.
Performance advantages:
1. Control system---- Mitsubishi PLC control system, random minitrim filling measurement
2. Control panel----7in. color screen, easy-operated , stable and reliable
3. Function improvement----The feeding nozzle is equipped with filling blocker(prevent leaking ,dropping and drawing). This machine can realize diving filling according to the material properties.(this function can be selected)
4. Real-time alarm----Automatic alarming when the fault happens, automatic stopping and alarming when the system appears serious breakdown.
5.Electrical elements----Adopting international famous brand to ensure the remarkable quality, stability and high precision.
6.Machine elements----The parts contacted with the material use the 316 high-quality stainless steel and non-poisonous, anti-corrosive PTEF hose. Other machine parts use the 304 high-class stainless steel
7. Counting detection----Real- time counting, reflecting the output directly.
8. Filling detection----No-bottle no-filling, it will not conduct filling if the bottles are not enough.
9. Maintenance condition----Fully accords to the GMP requirements, easy to disassemble and clean.
10. Changing specification----No need to change any components, easy to realize changing the bottle types by simple adjust
11. Environmental protection configuration----Equipped with eco-friendly frame, realizing more clean and sanitary operating environment.
Technical parameters:
1. Filling head: 8 heads (4//6/8/10/12 heads can be selected)
2. Application: 20ml-200ml(various bottle shapes)
3.Voltage: 220V/380V power:1 kw
4.Suitable bottle diameter: 50mm-110mm
5. Filling error: ≤±1%.
6. Filling Speed: ≤4000bottles/hour(100ml water for testing)
7.Overall Dimension: 2000mm * 2200mm * 1000mm
8. Air source requirements: stable 0.55Mpa-0.65Mpa air
9. Air-consuming amount: 1000L/minute
10. Machine weight: 450 kg
