Product Name |
oil press |
Model |
YZYX10-6/8/9/J-2 |
Processing capacity (t/24h) |
4.5 |
Oil content of dry cakes (%) |
≤8 |
Squeezing power (KW) |
11 |
Measurement (mm) |
1720X580X1185 |
Weight (KG) |
590 |
1,Gearbox :Cast iron bigger gearbox provide a strong foundation for operating smoothly and provide a long working life .
2, Feeder:carbon steel feeder
3, Squeeze cage: carbon steel lengthen squeeze cage (squeeze loop ,squeeze spiral can remove and changed after long time working)
The series YZYX10 spiral oil press produced by our company is suitable for squeezing vegetable oil from rapeseed, cottonseed, soybean, shelled peanut, flax seed, tung oil seed, sunflower seed and palm kernel, etc. The product has characteristics of small investment, high capacity, strong compatibility and high efficiency. It is widely used in small oil refinery and rural enterprise.
The product conforms to the “Technology Standard of Agricultural Spiral Oil Press” under JB/T9793·1-1999 of the People's Republic of China.
Under the combined effects of several forces, such as the pressure generated as the space in the squeeze chest becoming smaller, the propulsion of the revolving spiral axes, the resistance of the multilateral arc curves on the squeeze loops, the extrusion & friction between the oil plants, oil squeezed from the oil plants comes out from the squeeze bars and the grooves of the squeeze loops.
The residue is conveyed to the end of the press chest and discharges in thin strips of oil cake from the space between the cake adjuster and the loop for cake out.
Then the whole separation process of oil from oil plants is completed.
1. More than 30 types of oil plants, such as rapeseed, cotton seed, soybean, shelled peanut, flax seed, sunflower seed and palm kernel, etc.
2. Used in oil factory, oil mill and private oil production workshop.
3. Good both for pressing raw oil material and roasted oil material.
1. We supply spare parts all year around.
2. We supply technical solutions and helps for buyers at any time.
3. Have designers to help construct oil factory.
1. Since 1998, 17 years’ manufacturing experiences.
2. Covering an area of 50000 square meters, with more than 300 staffs, 10% are engineer and technician.
3. Comply I S O 9 0 0 1: 2 0 0 8 management system, in a leading position in China oil press industry.
4. We are an enterprise incorporating industry and export, provide overseas clients with prompt delivery and professional after-sale service.
FAQ
1. Delivery time.
---20~30 days after order confirmation. We need time to prepare machine according to exporting standard, wear-in, making wooden box, fumigation and suitable ship arrangement from forwarder.
2. If I don't know how to operate this machine? how can I do?
---Our machine has been tested OK and fully assembled before shipping, customer just needs to make
2~4 hours wear-in and then can work.
3. What's wear-in for new machine?
--- use 10 KG oil cake + 1KG sand + 1KG water, mix them, put in oil press, wear in 3~4hs.
1st hour, adjust oil cake thickness as 3mm.
2nd hour, adjust oil cake thickness as 2.5mm.
3rd hour, adjust oil cake thickness as 2 mm.
4. What are cold press and hot press?
---Cold press is pressing dry and raw seeds. Usually need to press 2 times to get maximum oil.
---Hot press is pressing roasted seeds. Usually only press 1 time to get maximum oil. peanuts roast to 125~130 degree with 1~2% moisture. (We produce seeds roaster heated by economical fuel.)
