lifting worktable1.SJYO.3-8 mobile scissor li
2.hydraulic lift
3.four-wheel mobile scissor lift
4.CE
lifting worktable
Mobiel Scissor Lifts Product Advantages:high working capacity, most spacious platforms for several people to work on,easily moved,high strength steel structures,smoothly lifting up and droping down, easily operated,few faults.
Moving method:4 wheel mible or 2 wheel towable, tyres are optional, it could be pnumatic rubber tyres,solid rubber tires or polyurethane tires.
Power sources: local power available at the working sites(110V,220V,380V,415V) Working heights: ranging from 4m,6m,8m,10m,12m,14m,16m,18m,20m(Please refer to the Products Specification List)
Applications: It is widely used for the equipments installations and maintenance at the following places like construction sites workshops,warehouse,granary,bus/railway stations,hotels,airports,gas station and aerial pipeline.
Model # |
Load Capacity |
Table Size |
Lifting Height |
Working Height |
Overall Dimensions |
Dry Weight |
SJY0.3-8 |
300Kg |
1800×1200mm |
8M |
9.7M |
2300×1500×1420mm |
1240Kg |
SJY0.5-8 |
500Kg |
1800×1200mm |
8M |
9.7M |
2300×1500×1450mm |
1400Kg |
SJY0.8-8 |
800Kg |
1800×1200mm |
8M |
9.7M |
2300×1500×1540mm |
1480Kg |
SJY0.3-9 |
300Kg |
1800×1200mm |
9M |
10.7M |
2300×1500×1500mm |
1000Kg |
SJY0.5-9 |
500Kg |
2000×1200mm |
9M |
10.7M |
2500×1500×1550mm |
1300Kg |
SJY0.3-10 |
300Kg |
2120×l200mm |
10M |
11.7M |
2600×1500×1550mm |
1400Kg |
SJY0.5-10 |
500Kg |
2120×l200mm |
10M |
11.7M |
2600×1500×1550mm |
1550Kg |
