Flat Panel Solar Water Heater,water heating
function:
1. Full auto-control water function.
2. Constant temperature, timing electric heater(Power 1.5-4.5KW)
3. Setting temperature(30centigrade-90 centigrade),setting water level(50%-100%)
4. Manual water, supply water of control temperature, auto-water after 15 minutes without water auto- stop after full.
5. Prevent frostbite circulation (Forcing circulation when water temperature of the heat collector below 2 centigrade
6. Manual circulation ( the time of circumfluence could been set 5-99 sec.)
Once open, hot water coming.
7. Supply hot water by manual pressure, manual close pressure or auto-close pressure function after 30 minutes.
8. Avoiding without water heater function (supply water level to 50% firstly ,then auto-startup electric heater whenwater level below 50%)
Specification:
-Inter tank:SUS 304-2B food grade stainless steel with thickness of 0.4mm-0.6mm
-Outer tank:Stainless steel/galvanized steel /color steel with thickness of 0.35mm
-Insulation layer thickness of tank:55mm
-Absorber dimension L*W*T:1840*980*0.15
-Absorber material:Red copper
-Header material:Copper T2
-Header tube size(L*W*T):1060mm*Φ25mm*0.62pcs
-Max.operation temperature:200°C
-ing pressure:120 °C
-Daily output volume:105-300L.
packaging:
1.Sample:wooden case packing
2.Container:carton case packing
shipping : within 7-15 work days
