Product Description
Product Name: 4 core flexible cables
Features:
1.YC type:nominal voltage:450V/750V
ntinuous permissible operating temperature of core shall not exceed 65degree
3.Application: various kins of portable electric equipments and can bear relatively mechninal forces and suits for greasy dirt condition and outside condition
Specification
Type |
cores×nominal cross section area(mm²) |
Conductive wire |
Average Diametr(mm) |
20°C conductor resistance≤(Ω/km) |
Re. weight |
||||
YC |
YCW |
||||||||
|
YC 245IEC66 (YCW) |
1×1.56 |
0.26 |
5.6 |
7.2 |
13.3 |
13.7 |
51.9 |
57.0 |
|
1×2.5 |
0.26 |
6.4 |
8.0 |
7.98 |
8.21 |
73.7 |
79.5 |
||
1×4 |
0.31 |
7.2 |
9.0 |
4.95 |
5.09 |
110.5 |
118.7 |
||
1×6 |
0.31 |
8.0 |
11.0 |
3.30 |
3.39 |
132 |
167.3 |
||
1×10 |
0.41 |
9.8 |
13.0 |
1.91 |
1.95 |
220.6 |
234.8 |
||
1×16 |
0.41 |
11.0 |
14.5 |
1.21 |
1.24 |
295.1 |
311.6 |
||
1×25 |
0.41 |
12.5 |
16.5 |
0.78 |
0.795 |
425.6 |
446.2 |
||
1×35 |
0.41 |
16.5 |
21.0 |
0.386 |
0.393 |
758.4 |
788.4 |
||
1×50 |
0.41 |
16.5 |
21.0 |
0.386 |
0.393 |
758.4 |
788.4 |
||
1×70 |
0.51 |
18.5 |
24.0 |
0.272 |
0.277 |
1334.1 |
1073.7 |
||
1×95 |
0.51 |
21.0 |
26.0 |
0.206 |
0.210 |
1324.7 |
1369.3 |
||
1×120 |
0.51 |
23.0 |
28.5 |
0.161 |
0.164 |
1593.9 |
1646.3 |
||
1×150 |
0.51 |
25.0 |
32.0 |
0.129 |
0.132 |
1971.6 |
2063.7 |
||
1×185 |
0.51 |
27.5 |
34.5 |
0.160 |
0.108 |
2425.6 |
2498 |
||
1×240 |
0.51 |
30.5 |
38.0 |
0.0801 |
0.0817 |
3081.3 |
3166.2 |
||
1×300 |
0.51 |
33.5 |
41.5 |
0.0641 |
0.0654 |
3730.7 |
3825.2 |
||
2×1.5 |
0.26 |
9.0 |
11.5 |
13.3 |
13.7 |
132 |
146.6 |
||
