0.66/1.14kv Coal Mine Cable

Name: 0.66/1.14kv Coal Mine Cable
Brand: JinFeng
SKU: 108335189

Negotiable MOQ: 1 Kilometer (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hunan, China

Brand Name:

JinFeng

Model Number:

MCPT3

Xiangtan Shenzhou Special Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any of china

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hunan, China

Brand Name JinFeng

Model Number MCPT3

Conductor Material Copper

Insulation Material Rubber

Jacket Rubber

Number of Conductors 4

Application 0.66/1.14KV coal winning machine

Product Description

Product Name: coal mine cable

Application:The product used as the electric connections of coal wining machine .

Operating temperature:90°c.

Type	Description	Application
MY-0.38/0.66	Coal winning rubber cable	0.38/0.66kv coal machine
MYP-0.38/0.66	Coal winning rubber shield flexiber cable	0.38/0.66kv coal machine
MYP-0.66/1.14	Coal winning rubber shield flexiber cable	0.66/1.14kv coal machine

Specification:

voltage of 0.38/0.66kv one core cable(MY-0.38/0.66)

core No.*conductor nomal section(mm)	move core insulation thick(mm)	shield thick(mm)	outer diametre(mm)
1*4	1.4	1.5	8.0-10.0
1*6	1.4	1.6	9.0-12.0
1*10	1.6	1.8	11.0-14.0
1*16	1.6	1.9	12.0-15.0
1*25	1.8	2.1	14.0-17.5
1*35	1.8	2.2	16.0-19.5
1*50	2.0	2.4	18.5-22.5
1*70	2.0	2.6	21.0-25.0
1*95	2.2	2.8	23.5-28.5
1*120	2.2	3.0	25.5-29.5
1*150	2.4	3.2	28.0-33.0
1*185	2.4	3.4	30.5-35.5
1*240	2.6	3.5	34.0-39.5
1*300	2.6	3.6	37.0-43.0
1*400	2.8	3.8	42.0-48.0

voltage 0.38/0.66kv

move core	earth core	move core insulation thick(mm)	shield thick(mm)	MY-0.38/0.66	MYP-0.38/0.66
3*4	1*4	1.4	3.5	19.0-22.5	22.0-26.5
3*6	1*6	1.4	3.5	21.0-25.5	24.0-29.0
3*10	1*10	1.6	4.0	25.0-30.0	28.0-32.5
3*16	1*10	1.6	4.0	27.5-32	30.5-35.5
3*25	1*16	1.8	4.5	32.5-37.5	35.5-41.0
3*35	1*16	1.8	4.5	35.5-41.0	38.5-44.5
3*50	1*16	2.0	5.0	41.5-47.5	44.5-51.0
3*70	1*25	2.0	5.0	46.0-53.0	49.0-56.0
3*95	1*25	2.2	5.5	52.5-59.5	55.5-63.0
3*120	1*35	2.2	5.5	56.0-63.5	59.0-67.0
3*150	1*50	2.4	6.0	62.5-70.5	65.5-74.0
