3.5ton Gasoline Forklift Trucks for sale
with Japanese Nissan Engine
| Model | FY35 | ||
| Power type | LPG&gasoline | ||
| Rated capacity | kg | 3500 | |
| Load center | mm | 500 | |
| Lift height | mm | 3000 | |
| Fork size L*W*T | mm | 1070x125x45 | |
| Mast tilt angle(F/R) | Deg | 6°/12° | |
| Front overhang(wheel center to fork face) | mm | 480 | |
| Ground clearance(bottom of mast) | mm | 135 | |
| length to face of fork(without fork) | mm | 2770 | |
| overall width | mm | 1225 | |
| mast lowered height | mm | 2115 | |
| Mast extended height(with backrest) | mm | 4160 | |
| overhead guard height | mm | 2090 | |
| Turning radius(outside) | mm | 2480 | |
| min. insecting aisle | mm | 2530 | |
| Travel(empty load) | km/h | 19 | |
| Lifting(full load) | mm/s | 420 | |
| Max. gradeability | % | 20 | |
| Front tire | 28x9-15-12PR | ||
| Rear tire | 6.50-10-10PR | ||
| Wheel Base | mm | 1700 | |
| Service weight | kg | 4500 | |
| Battery (voltage/capacity) | v/ah | 12/ 80 | |
| Engine model | k25 | ||
| Manufacturer | nissan | ||
| Engine rated output/r.p.m | kw | 37.4/2300 | |
| Engine rated torque/r.p.m. | n.m | 176.5/1600 | |
| Engine No.of Cylinder | 4 | ||
| Bore x stroke | mm | 89x100 | |
| Displacement | cc | 2488 | |
| Fuel tank capacity | L | 60 | |
| transmission type | hydraulic | ||
| transmission type/ | FED/RVS | 1/1 | |
| operating pressure for attachment | Mpa | 17.5 | |
As a professional manufacturer of forklift, we also can offer you customized service.
the following items are optional:
Tires: Pneumatic and Solid tire
Color: Yellow,red,orange, green, blue or customized.
Engine: Mitsubishi/XINCHAI/XINCHANG/
VOLVO/QUANXIN/XICHAI/ISUZU/Mitsubishi engine are optional
Mast: 2 stage mast,2-stage full free mast,3-stage full free mast
Power source:Diesel,Gasoline,LPG,CNG,AC/DC electric forklift are available
Attachment: Side shifter, ejector, soft clamp;paper roll clamp; bale clamp/pulp bale clamp; carton clamp; push/pull;pushoff; rotator; block clamp; drum clamp; fork clamp; fork positioner; fork extension .etc.
For the details of customized configurations, quotations and options, please contact with us.
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
We can supply the following product for you: 1-48Ton Diesel Forklift; 1-12Ton Electric Forklift; 1-7Ton LPG Forklift; CNG Forklift; 1.2-2Ton Electric Pallet Stacker; 1.3-3Ton Electric Pallet Truck; 2-3Ton Manual/ Hand Pallet Truck; 1.5-2.5Ton Reach Lift Truck; 2-3.5Ton Rough Terrain Forklift; 3-12Ton Side Loader; 1.6-2Ton Three Wheel Forklift.
We also can provide attachment for you, for example, paper roll clamp; bale clamp/pulp bale clamp; carton clamp; pusher/puller; pushoff; rotator; block clamp; drum clamp; fork clamp; fork positioner; fork extension; side shifter.etc.
1. Can you customize and design as the clients' requirement?
Goodsense will try its best to meet all kinds of clients' special requirements. And for new products that have not been into the market yet, we have our technical team to help the clients.
All kinds of attachments such as roll paper clamp, side shifter and so on can be available.
2. How long is the warranty of your products?
All of products are within 1 year / 1000 working hours whichever occurs earlier.
3. Can you produce the products labeled with the client's brand?
Yes, we can. Please provide us the authorization of the brand, so we can supply the product to you on an OEM basis.
4. What's the terms of payment?
It’s our practice to accept payment by T/T 30% deposit, 70%
5. Can i choose the lifting height?
Yes, you can. we have three types of mast: wide view mast; wide view 2-stage full free mast; wide view3-stage full free mast.
The lifting height is from 3m to 7m, please chat with us for details and price.
