Yag Laser Equipment

Yag Laser Equipment thumbnail-1
Yag Laser Equipment photo-1
US$ 35,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
YAG
Applicable Material:
Metal, Other, Metal, Stainless Steel,carbon steel,alloy stell,silver,titanium
Contact Supplier Request Quote Chat Now
Jinan Dowell Photoelectricity Equipment Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Laser Type YAG
Applicable Material Metal, Other, Metal, Stainless Steel,carbon steel,alloy stell,silver,titanium
Cutting Thickness 0.2-6mm(accordingto materials)
Cutting Area 1500*3000mm
Cutting Speed 0-4500mm/min YAG metal cutting
CNC or Not Yes
Cooling Mode Water Cooling
Control Software Nceditor
Graphic Format Supported AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Place of Origin Shandong, China
Brand Name DOWELL
Model Number DW-YAG500
Certification CE, ISO, GS, SGS, UL, CCC
After-sales Service Provided Engineers available to service machinery overseas

Specifications

yag laser equipment
1.High precision metal cutting
2.YAG generator 500w,650w
3.Saving material

                          yag laser equipment



1.yag laser equipment Product Feature

DW - YAG500 metal cutting machine is a collection of optical, mechanical and electrical professional laser cutting equipment,  it is produced by our Company, the key parts adopt imported components, has various advantages,such as novel appearance,       unique structure, easy operation,  fast cutting speed,high precision and stable performance, can be widely used in various types of metal cutting. Specific advantages are as follows:
1.High precision: positioning accuracy 0.05 mm, repetitive positioning accuracy to 0.02mm.                                                     2.Smooth cutting edge:no burr cut surface, surface roughness commonly controlled within Ra12.5 .
3.High cutting speed:Cutting speed can reach 4.5 m/min, the largest positioning speed can be up to 10 m/min, much faster than the speed of the line cutting.
4.Good cutting quality: trimming thermal effect is very small, little thermal deformation of workpiece, completely avoid materials   formed edge collapse when punching and shearing, kerfgenerally do not need secondary processing .
5.Save material: using a computer programming,can put the different shapes of products to nesting cut the entire board, maximize material utilization.

2.yag laser equipment Parameter

YAG laser cutting machine DW1530

Model

DW-YAG 1530

Working area

1500*300mm

Laser Type

YAG lamp-pumped solid laser generator

Laser power

500W /650W

Laser wave length

1064nm

Cutting speed

≤4500mm/min

Cutting thickness

0.2-6mm (according to material)

Resetting precision

±0.02mm

Minimum line width

0.2mm

Impulse frequency

1-600Hz

Transmission Method

Servo Ballscrew,Dual linear guide

Cooling method

5P specialized water-cooling system

Gross power(W)

15KW

Power supply

380V/50HZ/100A

Supporting Format

PLT, DXF, BMP, AI, DST, DWG, etc.

Net weight(kg)

2500kg
3.Machine details of yag laser equipment

4.Advantages of yag laser equipment

5.Applicable of yag laser equipment

It is applied to cut stailess steel, carbon steel, alloy steel, spring steel, silver, copper ,titanium and some metal plate and pipe.

6.Samples of yag laser equipment

7.Our company

JINAN DOWELL PHOTOELECTRICITY EQUIPMENT CO.,LTD  We have over more than 10 years production                      history  and strong R&D marketing system. DW-CNC is specialized in producing and exporting Engraving Machine, Laser Machine,
Plasma Machine, Cutting Plotter and Marking Machine.

8.After-sale service of yag laser equipment

Because we are direct manufacturers, we have professional technical staff to do after-sale service, the day after receiving the machine, please ask for the after-sale technical phone, since then the machine technical problems the user encountered in use, the technical staff will teach you how to use, and help you to solve all technical problems about the machine. Other problems
besides the technology, users can find customer communication to solution.
