Help CenterAUTO-WD Inclined Plane Device for Household Electric Equipment
Related Products
-
IEC61058 Button Life /durability TesterUS$ 1,000 - 3,000MOQ: 1 Piece -
IEC60695-11-5 Measure the Fire Hazard of the Electro Electric Equipments Needle Flame TesterUS$ 2,200 - 4,500MOQ: 1 Set
-
High Performance Adhesion Tester CoatingUS$ 998 - 2,000MOQ: 1 Piece
-
High Quality Scratch Adhesion TesterUS$ 998 - 2,000MOQ: 1 Piece
-
Hot Sale Abrasion Test Machine WireUS$ 998 - 2,000MOQ: 1 Piece
Inclined Plane Device is used to test the stability of an apparatus that requires a surface in order to work.The device cosist of a surface and an angle adjusting device with 0- 15 °
To determine the stability of electric appliances which are used on a table or on the floor
in accordance with IEC 60065 / 1998-07 clause 19.1, IEC 60335-1 / 1991-04 clause 20.1, IEC 60601-1 /1988 clause 24.1, IEC 60950 / 1991 + Amendments, modified, clause 4.1.1,EN 60335-1 / 1994 and A11 / 1995 clause 20.1, EN 60950 / 1992 + Amendments up to 1997 clause 4.1.1,VDE 0700 Part 1 / 10.95 clause 20.1 and Part 3 / 3.96 clause 20.1, VDE 0730 Part 1 / 3.72 clause 20a,VDE 0805 / 11.97 clause 4.1.1
| Types | Surface Diameter | Angle Range | Bearing Capacity | Rotate Way |
| AUTO-3 | 1000mm | 0-30 ° | 125KG | hand-actuated/dynamoelectric |
| AUTO-2 | 800mm | 0-30 ° | 80KG | hand-actuated/dynamoelectric |
| AUTO-1 | 600mm | 0-45° | 50KG | hand-actuated |
According to the price and efficiency,choose the best transportation for you.
1.This tester is used to test the stability of an apparatus that requires a surface in order to work.The tester consists of a surface and an angle adjusting device with angles 0~15°C.
2.The appliance is placed in any normal position of use on a plane inclined at an angle of 10°C.
3.To the horizontal,the supply cord resting on the inclined plane in the most unfavorable position. However,if part of an appliance comes into contact with the horizontal supporting surface when the appliance is tilted through an angle of 10°C.
4.The appliance is placed on a horizontal support and tilted in the most unfavorable direction through an angle of 10°C;Appliances provided with doors are tested with the doors open or closed, whichever is the more unfavorable.
5.Appliances intended to be filled with liquid by the user in normal use are tested empty or filled with the most unfavorable quantity of water up to the capacity indicated in the instructions.
1. High quality is always our key to market .
2. We will take photos or vidios of your order before shipment.
3. Engineering team is professional and will provide you with good after-sales service.
