UL60950 Figure NAF2 and NAF3 standard factory provide
Stainless Steel safety wedge probe
1.Application:
The NAF2 is one of two new accessibility probes required by UL 60950 for paper shredders. UL found that children and small women could touch hazardous parts of some shredders. The other probe now required in the standard is UL Articulated Finger Probe, Model ULP01.
This model NAF2 is mostly made of aluminum to conserve weight. The tip is made of stainless steel because aluminum is too soft to withstand possible contact with the cutting blades.
The probe is electrically conductive as required in the standard. Also there is a threaded connector in the handle to accept either a force gauge or a banana plug wire connection.
2. Technical parameter:
| Length | 300mm |
| Width | 50mm |
| Bendable Senction | 30/30/40mm |
| Material | stainless steel |
| Reference | UL60950 Fig NAF.2 and NAF.3 |
Product Details:
Our services
1. High quality products.
2. We will take photos of your order before shipment.
3. Engineering team is professional and will provide you with good after-sales service.
4. Quality assurance is 1 year.
The advantage of our company
1. Engineering team is professional and will provide you with good after-sales service.
2. Many years of experience in foreign export.
3. Delivery time is fast, and quick respond.
4. We will send a picture of the packaging and product before shipment.
Management philosophy
1) Customers are god. We will do our best to satisfy you.
2) We will protect our reputation.
3) The quality is the most important thing.
4) We will bear a strong sense of responsibility.
Looking forward to hearing your inquiry!~Thank you!
