Home > Lights & Lighting > LED Encapsulation Series > LED Module > Pixels 6mm Indoor Full Color Billboard xx New Image xx Xscreen Programmable Signvideo Display Function Led Backlit Display
Pixels 6mm Indoor Full Color Billboard xx New Image xx Xscreen Programmable Signvideo Display Function Led Backlit Display
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
p6module-027
Chip Material:
InGaN
Emitting Color:
Tri-Color(Red-Blue-Green)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2016 Hot Sale P10 Red Led Module P10 Single Red Module Red Led Module P10NegotiableMOQ: 1 -
Free Style Ph10 Running Message Text Led Display Board,full Color P10 Indoor Led Module,led Screen Module P10 With Good PriceNegotiableMOQ: 1
-
2016 Red Outdoor Programmable Led Scrolling Sign Message Board Display P10(CE & RoHS Complaint)NegotiableMOQ: 1
-
the Factory Wholedale Led Advertising Outdoor Display ScreenNegotiableMOQ: 1
-
P6 Indoor Full Color Led Panel Display xx New Image xx Video ScreenNegotiableMOQ: 1
Model Number
p6module-027
Chip Material
InGaN
Emitting Color
Tri-Color(Red-Blue-Green)
Luminous Intensity
10-12lm/led
Luminous Flux(lm)
54lm
Optical Attenuation(%)
0.1
Power Dissipation
0.5%
Color Rendering Index(Ra)
85
Color Temperature
3000-6000K
Operating Temperature(℃)
-20, 50
Storage Temperature(℃)
-35, 85
Place of Origin
Guangdong, China
Brand Name
DY
Certification
CE
Pixels 6mm indoor full color billboard xx new image xx xscreen programmable signvideo Display Function led backlit display
| The technical parameter of P6 led Display panel | ||
| Number | Item | P6 |
| 1 | Pixel pitch | 6mm |
| 2 | Size of module(wxh) | 160mm X160mm/192 X96mm |
| 3 | Resolution of module (wxh) | 32 dots X16 dots |
| 4 | Density of pixel | 27777dots/m² |
| 5 | Pixel configuration | 1R or 1G or 1B or rgb |
| 6 | Red wavelength | 625±2nm |
| 7 | Green wavelength | 525±2nm |
| 8 | Blue wavelength | 470±2nm |
| 9 | Colors | single color/rgb |
| 10 | Best viewing distance | 6-100m |
| 11 | Horizontal viewing angle | 120° |
| 12 | max power consumption | 550w/sqm |
| 13 | Brightness | >1600cd /sqm |
| 14 | Gray scale | 16bits per color |
| 15 | Color temperature | 3000-6000k |
| 16 | Control method | Synchronization & Asynchronization |
| 17 | Driving method | 1/8 scanning |
| 18 | Frame frequency | 60Hz |
| 19 | Refresh frequency | >300Hz |
| 20 | Working voltage | AC220V/110V±10% |
| 21 | IP grade | IP65 |
| 22 | Working temperature | -20°C~80°C |
| 23 | MTBF | >10000 hours |
| 24 | Lifespan | >100,000 hours |
| 25 | Defects rate | ≤0.00001(Led display line standard<0.0001) |
