Specifications
shoes cover Punching Machine:punching machine,pvc punching machine,pu punching machine
shoes cover Punching Machine(Leather Perforating Machine) Technical Data
ModelNK-CK155
Supply and voltage380V 50-60HZ
Height of moulds25mm
Ram pressure120ton
Air pressure6kg/cm2
Weight8500KG
Productivity2—8m/min
Rated power 18KW
Machine size 3220*1950*2000 mm
Paper shelf *300*850mm
Feeding shelf size 1950*1850*1450mm
Electricity box size 850*500*1250mm
Rewinding shelf size 2350*1850*1150mm
Power of main motor 11KW
Power of rewinding electrical machine 750W*5(pcs)
Paper shelf cylinder diameter 80mm
The waste of electricity 8-10kw/hour
The biggest diameter of paper 1400mm
The effective working width 1.6m
Tolerance:within 1 mm
Max thickness that can punch: better less than 10 mm or 20 mm (There are two kinds)
Features of shoes cover Punching Machine(Leather Perforating Machine)
1.The leather punching machine applies advanced numerically controlled technology,electrical technology and software technology.
a.Numerically controlled technology is the core of advanced manufacturing technology, and develops towards high-speed,high-precision,multi-function,intelligentize,systematization and high reliability.
b. For electrical technology of punching machine, Nekon leather Punching machine applies high-speed SOC singlechip, and achieves real-time control.
c. For software technology, leather punching machine applies Man-machine interface, simple operating and reliable running.
2.Mechanical Features of leather punching machine(Leather Perforating Machine)
a. Drawing-back treatment of punching machine
b. The spindle of punching machine applies 10m big lathe, and host machine is formed by planer type milling machine.
c. Leather punching machine is 8.5ton, and that can effectively assure the stability of machine.
d. Rewinding of leather punching machine applies magnetic powder separation and reunion , that assures the accuracy and tidiness of rewinding.
e. The pillow of leather punching machine applies copper bush structure of high-speed punching, that assures accuracy,high-resistance,lubrication.
f. Leather punching machine applies recycling cooling oil to sure lubrication, bring down the temperature.
3 Other Features of leather punching machine(Leather Perforating Machine)
a.The leather punching machine can punching and embossing.
