Help CenterSJSZ-65/132 Conical Twin Screw PVC Window Profile Making Line
Related Products
-
PVC Plastic Profile Window Profile Production LineUS$ 48,500 - 80,000MOQ: 1 Set -
SJSZ-65/132 UPVC Electric Trunking Extrusion LineUS$ 45,000 - 50,000MOQ: 1 Set
-
Plastic PVC Profile Extrusion MachineryUS$ 48,500 - 80,000MOQ: 1 Set
-
CHINAPLAS BEIERMAN SJZ-65 PVC Profile Production LineUS$ 48,500 - 80,000MOQ: 1 Set
-
CE/SGS Approved Turnkey PVC Extrusion Machine for ProfileUS$ 45,000 - 50,000MOQ: 1 Set
PVC window profile making line major parts list:
NO. |
Major parts |
Detail information |
1 |
DTC-500 Screw Loading Machine |
Driving motor: 2.2KW |
2 |
SRL-Z200/500 PVC Mixing Unit |
Driving motor:45/7.5KW, Capacity: 350KG/HOUR |
3 |
ZJF-300 Spring Loading Machine |
Driving motor: 1.1KW |
4 |
SJSZ-65/132 Twin Screw Extruder |
Driving motor: 37KW, Capacity: 180-250KG/HOUR |
5 |
PVC profile moulds |
depends on customer's drawings |
6 |
Vacuum Forming Table |
Tank length: 6000mm; vacuum pump: 5.5KW, 3pcs Water pump: 2.2KW, 1pc, stainless steel tank |
7 |
Profile Haul off-Cutting Machine |
Haul off motor: 1.5KW, 2pcs; cutting motor: 2.2KW, 1pc |
8 |
Profile Stacker |
Stacker Length: 4-5meter, automatic control |
PVC window profile making line designed for the PVC powder, PVC pellets extruding to profiles, trunks. The profiles can be used for PVC windows, doors making and other relative PVC profiles products.
PVC window profile making line mainly used in PVC door & window profile ,wide door plate,window profile ,extrusion of multi- holes pipe for passing through lines (four holes,six holes.seven holes,nine holes etc.)
For different sectional surface and molds ,different specifications of twin conical screws extruder can be chosen together with corresponding vacuum calibrating table ,haul-off unit ,cutting unit,tilters,etc.
Advantage:
- world famous brands major parts: SIEMENS motor, ABB/FUJI/LG/OMRON inverters, SIEMENS/Schneider contactors, OMRON/RKC temperature controllers, DELTA/SIEMENS PLC system
- Skilled workers for machines producing
- Experience engineers all with passports ready for customers services
- Good Prices get from square quantity major parts purchase with lower cost
- Full line running test for customer checking before delivery
