Specifications
plastic profile making machine-conical twin screw extruder
-vacuum pump forming
-150-200KG capacity
-CE/SGS approved
CE/SGS approved High Quality plastic profile making machine for Profile specially designed for the PVC powder, PVC pellets extruding to profiles, trunks. The profiles can be used for PVC windows, doors making and other relative PVC profiles products.
plastic profile making machine has the advantage of it can both purchase the PVC powder and PVC pellets as raw material of profiles,trunks making.
CE/SGS approved High Quality plastic profile making machine major parts list:
NO. |
Major parts |
Detail information |
1 |
DTC-500 Screw Loading Machine |
Driving motor: 2.2KW |
2 |
SRL-Z200/500 PVC Mixing Unit |
Driving motor:45/7.5KW, Capacity: 350KG/HOUR |
3 |
ZJF-300 Spring Loading Machine |
Driving motor: 1.1KW |
4 |
SJSZ-65/132 Twin Screw Extruder |
Driving motor: 37KW, Capacity: 180-250KG/HOUR |
5 |
PVC profile moulds |
Profile size: according to customers drawings |
6 |
Vacuum Forming Table |
Tank length: 6000mm; vacuum pump: 5.5KW, 3pcs Water pump: 2.2KW, 1pc, stainless steel tank |
7 |
Profile Haul off-Cutting Machine |
Haul off motor: 1.5KW, 2pcs; cutting motor: 2.2KW, 1pc |
8 |
Profile Stacker |
Stacker Length: 4-5meter, automatic control |
Advantage:
- world famous brands major parts: SIEMENS motor, ABB/FUJI/LG/OMRON inverters, SIEMENS/Schneider contactors, OMRON/RKC temperature controllers, DELTA/SIEMENS PLC system
- Skilled workers for machines proucing
- Experience engineers all with passports ready for customers services
- Good Prices get from square quantity major parts purchase with lower cost
- Full line running test for customer checking before delivery
