R1 Agricultural Tractor Tire
R1 Agricultural Tractor Tire for Irrigation 14.9-24
Agricultural Tractor Tire features:
Excellent dragging performance.
Designed with big pattern block and deep pattern depth, with longer service life.
Excellent abrasion resistance performance.
Outstanding block-dropping resistance performance.
MORE SIZE AND PATTERN FOR YOU CHOOSE
| SIZE | PLY | TYPE | Bar Height | Standard Rim | Available Rim | Section Width | Overall Diameter | Max Load KG | Pressure (kpa) | |||
| mm | inch | mm | inch | mm | inch | |||||||
| 7.50-18 | 6 | TT | 14 | 0.55 | 5.50F | 203 | 7.99 | 850 | 33.46 | 950 | 225 | |
| 8 | TT | 1135 | 270 | |||||||||
| 11-38 | 6 | TT | 32 | 1.26 | W10 | DW10 | 305 | 12.01 | 1540 | 60.63 | 1400 | 140 |
| 8 | TT | 1545 | 160 | |||||||||
| 12.4-28 | 6 | TT | 34 | 1.34 | W11 | W10/W10H | 315 | 12.4 | 1260 | 49.61 | 1275 | 170 |
| 8 | TT | 1510 | 230 | |||||||||
| 10 | TT | 1700 | 280 | |||||||||
| 12 | TT | 1830 | 320 | |||||||||
| 13.6-28 | 6 | TT | 37 | 1.46 | W12 | W11 | 345 | 13.58 | 1310 | 51.57 | 1430 | 160 |
| 8 | TT | 1645 | 200 | |||||||||
| 10 | TT | 1910 | 250 | |||||||||
| 12 | TT | 2125 | 300 | |||||||||
| 18.4-30 | 6 | TT | 37 | 1.46 | W16L | W15/DW16 | 467 | 18.39 | 1550 | 61.02 | 2120 | 110 |
| 8 | TT | 2415 | 140 | |||||||||
| 10 | TT | 2815 | 180 | |||||||||
| 12 | TT | 3180 | 230 | |||||||||
| 18.4-34 | 6 | TT | 37 | 1.46 | W16L | W15/DW16 | 467 | 18.39 | 1655 | 65.16 | 2250 | 110 |
| 8 | TT | 2565 | 140 | |||||||||
| 10 | TT | 2990 | 180 | |||||||||
| 12 | TT | 3375 | 230 | |||||||||
| 14 | TT | 3630 | 260 | |||||||||
| 18.4-38 | 6 | TT | 37 | 1.46 | W16L | W15L | 467 | 18.39 | 1755 | 69.09 | 2380 | 110 |
| 8 | TT | 2715 | 140 | |||||||||
| 10 | TT | 3165 | 180 | |||||||||
| 12 | TT | 3575 | 230 | |||||||||
| 14 | TT | 3840 | 260 | |||||||||
agricultural tire for tractor
We are a professional manufactory and exporter of Chinese Radial tires,heavy and light truck tires,OTR tires,agricultural and industrial tires,is devoted itself to China’s rubber and tyre industry all along since founded.
Professional · Focus - first-class production line of first-class products
Our company has introduced from Germany, Italy, Korea, Japan and other countries and
regions, the introduction of a variety of advanced production and testing instruments and
equipment, and professional quality inspection centers and research institutions.
lStrict Test in condition of international standard request:
Durability Test: our tyres can keep running more than 100 hours in the durability
test, while the standard request is only less than 50 hours
lBead Durability Test:our tyre can keep running more than 40 hours in the
condition of 70% of standard pressure and double standard loading capacity, while
standard request is only less than 20 hours, that means our tyres own very strong
inner constitution, especially for the bead position,3 kinds different rubber
compound and full steel wrapped inside, all of them can ensure the excellent
performance with full or extra loading, by such strong tyre constitution, our tyres
could be treaded 2 or 3 times.
lThe technical and reasonable design: 0°C belt plyer structure.
lMaterials:1.All-nature rubber from Malaysia, which could provide the radials’ required sturdiness.
2. Bekaert wire, which is NO.1 in the world.
3. Super wear-resistance of Cabot carbon black.
lStrict cure test---more than 20 wires connected to every part of the tire to make sure the tire achieves the best cure results.
lCertificates --- U.S.A. DOT, European ECE & E-Sound, Saudi Arabia GCC, ISO &CCC China compulsory product certification.
lExport To---Africa, America, Asia, India, Oceania and Europe, etc.
