Newest EXFO OTDR FTB-2/FTB-2 Pro Platform upgrade from FTB-200
Tel:+86-755-36934393
Fax: 0086-755-33503470
Website: www..hk
Skype: kitty.hsv
Specification:
FTB-2/FTB-2 Pro Platform THE MOST COMPACT MULTITECHNOLOGY PLATFORM AVAILABLE FOR THE SUPERTECH.The FTB-2, available in a standard or Pro model, is the most compact solution on the market for 10M-to-100G multitechnology and multiservice testing.
KEY FEATURES Connects anywhere: USB, mobile, Wi-Fi, virtual private network (VPN) and Bluetooth
Loaded with utilities: equipped with all the tools required to maximize testing, and any third-party application
Like a PC: available with a dual- or quad-core processor and Windows-based operating system
EXFO Connect-compatible: automated asset management; data goes through the cloud and into a dynamic database
Description:
| Includes : | - Instruction Manual (Soft Copy) |
| (Mainframe) | - Quick Reference Guide (Hard copy) |
| - GP-2090: Li-Ion smart battery (qty:1) | |
| - GP-2021** or GP-2233**: 90W, AC Adapter with power cord (see GP description for details) |
|
| - GP-2214: Hand strap | |
| - GP-2215: Handle |
Features:
2-slot capacity Modular mainframe
Windows Embedded 8 Standard OS, DUAL Core CPU
- Touchscreen, color, 1280 x 800 TFT, 256 mm (10.1 in)
- RAM: 4 GB Internal memory
- Interfaces:
> RJ-45 LAN 10/100/1000 Mbit/s
> USB 2.0 ports (qty:2)
> USB 3.0 port
> Display port
> 3.5 mm audio jack (speaker/mic)
[Notes]
! First module MUST be a FTBx OTDR module
KEY FEATURES
| FTBx-720C-SM1-XX | SM OTDR Module 1310/1550 nm, 36/35 dB (9/125 µm) |
| FTBx-720C-SM2-XX | SM OTDR Module Port 1: 1310/1550 nm, 36/35 dB (9/125 µm) Port 2: Filtered 1625 nm, 35 dB (9/125 µm) for live fiber testing |
| FTBx-720C-Q1-XX | MM OTDR Module Port 1: 850/1300 nm, 27/29 dB (50/125 & 62.5/125 µm) Port 2: SM Hardware ready and field upgradable to 1310/1550 nm |
| FTBx-720C-Q1-QUAD-XX | QUAD OTDR Module Port 1: 850/1300 nm, 27/29 dB (50/125 & 62.5/125 µm) Port 2: 1310/1550 nm 36/35 dB (9/125 µm) |
| FTBx-730C-SM1-XX | SM OTDR Module 1310/1550 nm, 39/38 dB (9/125 µm) |
| FTBx-730C-SM2-XX | SM OTDR Module Port 1: 1310/1550 nm, 39/38 dB (9/125 µm) Port 2: Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing |
| FTBx-730C-SM3-XX | SM OTDR Module 1310/1550/1625 nm, 39/38/39dB (9/125 µm) |
| FTBx-730C-SM8-XX | SM OTDR Module Port 1: 1310/1550 nm, 39/38 dB (9/125 µm) Port 2: Filtered 1650 nm, 39 dB (9/125 µm) for live fiber testing |
| FTBx-730C-SM6-XX | SM OTDR Module Filtered 1625 nm, 39 dB (9/125 µm) for live fiber testing |
| FTBx-730C-SM7-XX | SM OTDR Module Filtered 1650 nm, 39 dB (9/125 µm) for live fiber testing |
| FTBx-735C-SM1-XX | SM OTDR Module 1310/1550 nm, 42/41 dB (9/125 µm) |
| FTBx-735C-SM2-XX | SM OTDR Module Port 1: 1310/1550 nm, 42/41 dB (9/125 µm) Port 2: Filtered 1625 nm, 41 dB (9/125 µm) for live fiber testing |
| FTBx-735C-SM3-XX | SM OTDR Module 1310/1550/1625 nm, 42/41/41 dB (9/125 µm) |
| FTBx-735C-SM4-XX | SM OTDR Module 1310/1490/1550 nm, 42/41/41 dB (9/125 µm) |
| FTBx-740C-DWC | SM Tunable DWDM OTDR Module C-band 1528/1563 nm, 100/50 GHz, 40 dB (9/125 µm) |
| FTBx-750C-SM1 | SM OTDR Module 1310/1550 nm, 46/45 dB (9/125 µm) |
| FTBx-750C-SM3 | SM OTDR Module 1310/1550/1625 nm, 45/45/45 dB (9/125 µm) |
