Digital gauss meter tesla meter
Features of Digital gauss meter tesla meter:
WT10A type hand-held digital gauss meter used to measure the magnetic field of permanent magnet material surface, dc motor, speaker, magnetic separator, permanent magnetic iron remover work field and leakage magnetic field, parts machining after the residual magnetic field demagnetization. The instrument can carry, wide range, convenient operation, clear liquid crystal display (LCD).
Technical Parameters of Digital gauss meter tesla meter:
1. Measure range: 0~200mT~2000 mT Frequency: 10Hz~200Hz
2. Accuracy: 1%(0~100mT),2%(more than 100mT)
3. Resolution: DC×1 :0.00~200.00mT 0.01mT
DC×10:0.0~2000.0mT 0.1mT
AC×1 :0.00~200.00mT 0.01mT
AC×10:0.0~2000.0mT 0.1mT
4. Measured magnetic field: DC magnetic field (static magnetic field)
AC magnetic field (dynamic magnetic field)
5. Function description:Peak hold function
6. Gs/mT (Tesla) can freely switch
7. DC measurement with NS polarity display. N stands for positive, S for the negative electrode
8. Display key fast automatic zero
9. Ambient temperature: 5℃~40℃
10. Relative humidity: 20%~80% (no condensation)
11. Power supply: Six section 5 dry battery external 9V power supply
12. Dimension: 150mm(L)×70mm(W)×30mm(H)
13. Instrument weight: 450g
14. Display mode: 4 1/2 LCD
15. Display unit: mT/Gs
