Help CenterW11S 30*3000 Hydraulic Plate Rolling Machine
Related Products
-
W11S 30*3000 Hyraulic Plate Rolls MachineUS$ 1 - 82,222MOQ: 1 Set -
W11S NC Upper Roll Milt-function Rolling MachineUS$ 1 - 82,222MOQ: 1 Set
-
Hydraulic Upper Roller Universal Rolling Machine W11S-20x3200US$ 1 - 82,222MOQ: 1 Set
-
Hydraulic Universal Roll Bending Machine W11S-20x3200US$ 1 - 82,222MOQ: 1 Set
-
Hydraulic Universal Rollers Bending Machine W11S-20x3200US$ 1 - 82,222MOQ: 1 Set
Specifications
W11S 20*2500 hydraulic sheet metal Plate Rolling MachineCone device
Up driver roller
Pre-bending function
ISO&CE
W11S 30*3000 Upper Roller Universal Plate Rolling Machine
The machine’s use
1. High productivity and good precision for metal sheets bending, different up-die and bottom-die, working for multifarious pieces. One-off bending shaped by one time stroke. Can make complex shapes by repetitious bending work. Can punch with corresponding die.
2. Mechanical stopper in oil cylinder, typical of high feedback precision for position of gliding block ,accurate and stable operation,good synchronizing performance ,and high repeated positioning precision of gliding block.
Model |
Plate width |
Max. plate thickness |
Pre-bending thickness (mm)
|
Minimum reel diameter |
Plate yield limit (MPa) |
Diameter of upper roller (mm) |
Diameter of lower roller (mm) |
Diameter of side roller (mm) |
W11S-12×4000MM |
4000 |
12 |
8 |
800 |
245 |
380 |
340 |
280 |
W11S-16×3200 |
3200 |
16 |
12 |
800 |
245 |
380 |
340 |
280 |
W11S-20×2500 |
2500 |
20 |
16 |
800 |
245 |
380 |
340 |
280 |
W11S-25×2000 |
2000 |
25 |
20 |
800 |
245 |
380 |
340 |
280 |
W11S-32×2500 |
2500 |
32 |
25 |
1500 |
245 |
520 |
500 |
350 |
W11S-32×4000 |
4000 |
32 |
25 |
1300 |
245 |
650 |
580 |
480 |
W11S-40×3200 |
3200 |
40 |
32 |
1300 |
245 |
650 |
580 |
480 |
W11S-45×2500 |
2500 |
45 |
40 |
13600 |
245 |
650 |
580 |
480 |
W11S-50×2000 |
2000 |
50 |
42 |
1300 |
245 |
650 |
580 |
480 |
W11S-50×3200 |
3200 |
50 |
40 |
1800 |
245 |
680 |
650 |
520 |
CE Certification for our quality machines:
Notes of Both factories:
Jiang Su Hairui CNC Machine Tool Co,.Ltd and Anhui Haili Machine Tool Co., Ltd belongs to the same boss. Both company are focusing on press brake, shearing machine, notching machine and v groover machine , rolling machine and so on! When Hairui factory is newly built up for manufacturing higher standard CNC machines, please understand! We had passed CE, ISO, BV certifications in the past years.
How to reach our factory:
True strength weclome your inspection! Our factory is about 30km far away from Shanghai. You can come here by train or air to Nanjing, which takes you 2 hours at most. We will pick up you from the train station or air port.
Warranty of our machines:
One year warranty for the main components, 5 years for the whole structure.
Professional manufacturer of CNC press brake, shearing machine,
notching machine and v groover machine , rolling machine and so on.
