Help CenterLow Price Waste Tire/tyre Recycling Line Wire Baler Manufacturer
Related Products
-
Low Price Waste Tire/tyre Steel Wire Baler ManufacturerUS$ 1,000 - 1,000,000MOQ: 1 Unit -
Low Price Waste Tire/tyre Steel Wire Extractor MachineUS$ 1,000 - 1,000,000MOQ: 1 Unit
-
Clothes BalingNegotiableMOQ: 1 Unit
-
Automatic Waste Baler MachineNegotiableMOQ: 1 Unit
-
Aluminium Bale MakerNegotiableMOQ: 1 Unit
Specifications
tire/tyre recycling line wire baler1.easy installation
2.Environment friendly
3.Low price,high profit
4.Low noise
This machine will densify large quantities of wire difficult to handle. Unparalleled briquette density, integrity and throughput provides a significant additional evenue stream for your tire recycling operation.
Tire Recycling line wire Baler to process materials including:
1.Tire Wire
2.Copper
3.Aluminium
4.Brass
5.Etc
Advantage:
Peak control
Our control system of the regulated pumps prevents the cost-intensive current peaks with the courses of motion.
Cost
Fewer energy costs by low connected load.
Filter
Two-way tank system with filter cleaning.
Efficient
Continuous work routine filling during the press process.
Cylinder protection
The length measuring system are integrated in the protects hydraulic cylinders.(disturbances by external sensors belong to the past)
Manufacturing
Internal manufacturing guarantees quality and rapid spare and wearing parts availability.
Service life
Small oil temperature by achievement-regulated pumps, higher service life of the hydraulic oil.
Tire Recycling Process:
Dura-Shred uses its experience and success to continually improve the design and manufacturing of our tire recycling systems to make them more effective and efficient throughout the reduction process. The reduction from whole tires to crumb rubber is accomplished through our:
1.Prime Shredder
Dura-Shred Dual Shaft Shredder 150: 150 hp rotating the blades, truck and car size tires are reduced to rough 3”shredded strips through the Prime Shredder. Rough shred is then recirculated until it can be sent to the Grater via a conveyer.
2.The Grater
Dura-Shred Grater 150: The Grater takes the chips and reduces them to 10mm-12mm. At this point 95%-97% of
the steel has been stripped and is removed with our magnet belt as the rubber mulch is transported
to the vibratory tables for separation. This will be the end of the mulch producing line. For crumb
rubber steel free mulch will be sent via conveyor to the Granulators for further processing.
3.Granulator
Dura-Shred Granulator: The G1 reduces the rubber down to a 5mm-7mm or 10-20 mesh, which is then removed
through a screening system. Additional steel and fiber are then removed through an air and vibratory
system before being sent to the surge bin for collection.
Scope of Project:
System is designed to produce the following byproducts: Steel, Fiber, Tire Derived Fuel Chips (TDF), Rubber
Mulch, Rubber Powder.
System Capacity:
Capacity for this system is 2.5 metric tons of input per hour.
Crumb Size:
10mm - 14mm Mulch (Can be removed after The Grater)
4mm-6mm and 10 / 20 mesh. (After the Granulators)
Crumb Rubber Purity:
95% Free of Textile.
95% Free of Steel.
95% Free of Stones and other contaminants.
Steel Purity:
92%-94% Contaminant free.
Power:
Power Type: 440V / 3Ph / 60Hz
Total Kilowatts: 607
Estimated Power Usage Per Hour of Operation: *** $65.56
***Based on a price of $018 per kilowatt hour.
Development space of market:
The method of recycling waste tyre is that separating the inner steel wire and fiber from waste tires through many kinds of technologies and grinding the rubber granules into powder.Waste tyre treatment equipment are suitable for international development and management style. It’s most advantage is it can recovery waste tyres to rubber granules/powder reaching to the availability 100%.
The rubber powder is widely used and almost covers all industrial fields. It can replace the material such as plastic and PVC, instead of nature rubber, be rebirth tires .It is used in sport runway and shoe soles; it also can be used to highway, air trip as well as third generation railway sleeper as modification asphalt.
Process:
Waste tyres- thick steel wire taking out——whole tyre cutting into large blocks(four or two pieces)—— rough shredding tyre blocks into pieces (50mm-100mm)——medium shredding into smaller ones(10mm-20mm)——fine shred into granules(3mm-4mm)——grind the granules into powder(20-100mesh)——magnetic separator for thin steel removing——fiber separator for rubber removing——packing
Rubber powder application:
1.Paving sport ground:
Runway, school sporting field, garden path, bowling alley, pavement, recreation field, basketball field, etc.
2.Automobile industry:
Train’s floor, disc silk ribbon for braking, soleplate of automobile and truck, shake sleeve, seal stripe, buffer, shock absorber, daily material for ocean shiping, tyres and inner unerlay of tyres, etc.
3.Architecture and equipment:
Adhensive/sealant, floors of hospital, company, insulated rubber material, carpet cushion, grass cushion for family animal, extruded products, module products, coating, bricks, thin slice, water-proof material, etc.
4.Application of geotechnical/asphalt
Drainage pipe, asphalt modified by rubber powder which can be used to construct highway and drivingway, filter, adjusting soil/coating layer for road surface, washing pipe with holes, runway for horse race, barrier for traffic or pavement, etc.
5.Regenerative rubber:
Rubber products manufacturing.
6.Other application
Proven Design and Technology.
A quality system with at an affordable price!
Fully Automated via 1 centrally located touch screen control panel.
Backed with one of the best Warrantees in the industry
Plz enquiry us freely,if you got any questions.
