Brand Name
Jinlida
Model Number
JINLIDA-15
Application
Gabion
Material
high galvanized hot dipped galvanized steel wire
Wire Gauge
2.0-4.0mm
Mesh Size
60x80mm, 80x100mm,100x120mm
Hole Shape
Hexagonal
Surface Treatment
Galvanized
Specifications
hot dipped galvanized gabionMaterials: low carbon Hot dipped and high galvanized steel wires
Why chose JINLIDA GABIONS:
1. The earliest gabion and largest manufacturer in China.
2. The only one enterprise recommended by China Ministry of Water Resources in the field of gabion structures.
3. Member of Chinese Hydraulic Engineering Society(CHES).
4. Gabions strictly implement and meet ASTM A-975 or EN10244-2
GABION SIZE | |
Mesh opening |
60x80mm, 80 x 100 mm, 100x120mm,etc. |
Wire size |
2.0mm, 2.2mm, 2.4mm, 2,7 mm, 3.0mm, 3.2mm, etc. |
Tolerance | |
Lenght |
± 3% |
Width |
± 5% |
Height |
± 5% |
Materials | |
Heavy and hot dipped galvanized low carbon steel wires, galfan(Zn 5%Al), Zn 10% Al, pvc coated | |
|
Zinc/galfan/ Zn 10%Al coating 2.2mm/2.4mm≥270gsm 2.7mm/3.0mm/3.4mm≥300gsm
| |
Thickness of pvc coating: 0.5mm | |
