Hot Dip Wire Galvanizing Line

Hot Dip Wire Galvanizing Line thumbnail-1
Hot Dip Wire Galvanizing Line photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Coating Production Line
Coating:
Galvanizing
Place of Origin:
Contact Supplier Request Quote Chat Now
Jiangyin Jinlida Light Industry Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Coating Production Line
Coating Galvanizing
Brand Name Jinlida
Model Number Jinlida 23
Certification ISO9001

Specifications

Production process: paying-of / degreasing / washing / acid-washing / hot-washing / fluxing / drying / hot dip galvanizing / tak

Technology parameters:
1) Raw materials: Q195 or Q 235 (GB/T700-1988) or C10 (ISO683/11-1987)
2) Wire diameter: 1.6 - 3.5mm
3) Typical specification: 2.2mm
4) Weight of zinc coat: 60 - 300g/m²
5) Quantity of the lines: 32 lines
6) Power of product line: 428kW (horizontal type wire taking up machine),
476.4kW (vertical type taking up machine)
7) Speed of product line: 5 - 20m/min
8) Producing ability (daily output): max. 21T (3.5mm), min. 11T (1.6mm)
9) Daily work time: 24hrs
10) Size of product line: 90m x 3m
11) Weight of product line: about 40T
