custom7 segments led display screen for home appliance
Specification
1.Electrical optical charactertistics(Ta25°C)
Parameter |
Symbol |
Min |
Type |
Max |
Unit |
Test Condition |
Luminous Intensity |
IV |
165 |
182 |
185 |
mcd |
IF=20mA |
Peak Wavelength |
λp |
|
|
|
nm |
IF=20mA |
Dominant Wavelength |
λd |
510 |
511 |
512 |
nm |
IF=20mA |
Forward Voltage |
Vf |
3.0 |
3.2 |
3.5 |
V |
IF=20mA |
Reverse Current |
IR |
|
|
50 |
uA |
VR=5V |
Suggestion Forward Current |
IF |
3 |
5-10 |
20 |
mA |
IF=20mA |
2.Absolute Maximum Ratings (Ta=25°C):
Parameter |
Rating |
Unit |
Reverse Voltage |
5 |
V |
Power Dissipation,Per Dice |
50 |
mW/chip |
Operating Temperature Ranger |
-48~+85 |
°C |
Storage Humidity |
45%~85% |
°F |
Storage Temperature Ranger |
-40~+90 |
°C |
Soldering Temperature |
260°C For 3 Seconds |
|
Peak IF(ma) (1/10Duty Cycle 0.1ms Pulse Width) |
100 |
mA/chip |
Continuous Forward Current |
20 |
mA/chip |
Design paper
Introduction of Our Company
SHENZHEN AITEAI TECHNOLOGY CO.,LTD.
Our company is specialized in LED diode, nixie tubes, dot matrix modules, clock plate, back plate, and all kinds of indoor and outdoor LED display screen with single or dual color etc.Our products sells well for uniform brightness and enjoys a great reputation in China .
Our products decease less than 1% brightness within 1 year. With many years experience in production and management, we can offer customers with reliable quality, favorable price of LED display.
Our belief is "to pursuit excellence on the basis of good faith". Our purpose is to provide our customers the best quality and service. Besides, we have rich experience in cooperating with some big companies such as TCL, Desay etc.
We do believe we can become your reliable supplier!
