Low Price HM6730 China 10-30 Seat Bus With Double Doors

Name: Low Price HM6730 China 10-30 Seat Bus With Double Doors
Brand: HUAXIN
SKU: 109272219

US$ 20,000 - 30,000 MOQ: 2 Units

Key Specifications

Seats:

21 - 40

Transmission Type:

Manual

Max Speed:

51 - 70 km/h

Wuxi Huace Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Seats 21 - 40

Transmission Type Manual

Max Speed 51 - 70 km/h

Steering Position LHD

Fuel Type Diesel

Dimensions (L x W x H) (mm) 7300*2240*2900/3100

Place of Origin Jiangsu, China

Brand Name HUAXIN

Model Number HM6730CFD

Name: Hot Selling 7.3m bus (hm6730)

Specifications
Model			HM6730
DIMENSIONS & WEIGHTS
Overall dimension (mm)		Length	7288
		Width	2240
		Height	2780/2990
Wheelbase (mm)			3300
Thread (mm)		Front/rear	1830/1600
Seating capacity (persons)			27(double doors)30 (single middle passenger door)
ENGINE
Model
Type			4-cylinder, in line, water-cooled, direct injection, diesel, turbocharged, inter-cooling
Displacement (cc)			4500
Max. Power (hp/rpm)			140/2500
Max. Torque (N-m/rpm)			450/1400
Fuel tank (liter)			90
DRIVE TRAIN
Clutch			Hydraulic, Single plate, dry type diaphragm spring
Gearbox			5 speed manual
Max. gradeability (%)			30
CHASSIS
Frame			Ladder shaped, ‘] ’ section
Suspension, front/rear			Leaf springs
Shock absorber, front/rear			Double action shock absorbers
Steering			Recirculating-ball
Brake	Type		Air brake
	Front/rear		Drums
Power steering			With
Tires			7.50-16
FOB SHANGHAI
