7m Euro 3 Luxury Diesel Engine Manual Coaster Mini Bus

Name: 7m Euro 3 Luxury Diesel Engine Manual Coaster Mini Bus
Brand: HUAXIN
SKU: 109272843

US$ 17,000 - 30,000 MOQ: 2 Units

Key Specifications

Seats:

16 - 30

Emission Standard:

Euro 3

Transmission Type:

Manual

Wuxi Huace Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhangjiagang

Delivery Detail:

Delivery time depends on order quantity.

Seats 16 - 30

Emission Standard Euro 3

Transmission Type Manual

Condition New

Fuel Type Diesel

Place of Origin Jiangsu, China

Brand Name HUAXIN

Model Number HM6700

Name of Product: 7m Euro 3 Luxury Coaster Mini Bus with diesel engine

Specifications
Model			HM6700
DIMENSIONS & WEIGHTS
Overall dimension (mm)		Length	7005
		Width	2040
		Height	2730
Wheelbase (mm)			3935
Thread (mm)	Front/rear		1665/1525
Curb vehicle weight (kg)			4100
Gross vehicle weight (kg)			6500
Seating capacity (persons)			23+6
ENGINE
Model			CY4102BZLQ
Type			4-cylinder, in line, water-cooled, direct injection, diesel, turbocharged
			Inter-cooling
Displacement (cc)			3856
Max. Power (hp/rpm)			120/2800
Max. Torque (N-m/rpm)			343/1600
Fuel tank (liter)			85
DRIVE TRAIN
Clutch			Hydraulic, Single plate, dry type diaphragm spring
Gearbox			5 speed manual
Max. gradeability (%)			30
CHASSIS
Frame			Ladder shaped, ‘] ’ section
Suspension, front/rear			Leaf springs 3/4
Shock absorber, front/rear			Double action shock absorbers
Steering			Recirculating-ball
Brake	Type		Air brake
	Front/rear		Drums
Power steering			With
Min. turning radius (m)			7.5
Tires			7.00-16 14PR
FOB SHANGHAI
