Home > Electrical & Electronics > Relay & Contactor > Relay > DIN Rail Mount SSR Crydom Solid State Relay Model DRA1-CX240D5 DC Control SSR

DIN Rail Mount SSR Crydom Solid State Relay Model DRA1-CX240D5 DC Control SSR

Name: DIN Rail Mount SSR Crydom Solid State Relay Model DRA1-CX240D5 DC Control SSR
Brand: CRYDOM
SKU: 109307529

DIN Rail Mount SSR Crydom Solid State Relay Model DRA1-CX240D5 DC Control SSR thumbnail-1

DIN Rail Mount SSR Crydom Solid State Relay Model DRA1-CX240D5 DC Control SSR photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Mexico

Brand Name:

CRYDOM

Model Number:

CX24OD5

Contact Supplier Request Quote Chat Now

Beijing Shuntu Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Mexico

Brand Name CRYDOM

Model Number CX24OD5

Theory Solid State Relay

Usage General Purpose

Size Miniature

Protect Feature Sealed

Contact Load Low Power

Specifications

DIN rail mount SSR Crydom solid state relay model DRA1-CX240D5 DC control SSR
DRA1 CX Series SSR - Ratings to 5A
micro SSR

DIN rail mount SSR Crydom solid state relay model DRA1-CX240D5 DC control SSR
DRA1 CX Series SSR - Ratings to 5A
micro SSR catalogue PDF
• 10mm Single Channel DIN Rail Mount SSR Assembly
• AC Ratings up to 380 VAC and 5 Amps
• 3-15 and 15-32VDC control
• Cage style screw terminals for easy connection
• Fits standard 35mm DIN rail
• Includes LED Status indicator
- SCR output for heavy industrial loads
- Zero-crossing (resistive loads) or random-fire (inductive loads) output
Part Number Control Voltage Maximum Load Current Line Voltage Range Input Specification PDF
DRA1-CX240A5 90-140 VAC 5 Amps 12-280 VAC
DRA1-CX240A5R 90-140 VAC 5 Amps 12-280 VAC
DRA1-CXE240A5R 18-36 VAC 5 Amps 12-280 VAC
DRA1-CXE240A5 18-36 VAC 5 Amps 12-280 VAC
DRA1-CX240D5R 3-15 VDC 5 Amps 12-280 VAC
DRA1-CXE240D5R 15-32 VDC 5 Amps 12-280 VAC
DRA1-CX240D5 3-15 VDC 5 Amps 12-280 VAC
DRA1-CXE240D5 15-32 VDC 5 Amps 12-280 VAC
DRA1-CX380D5R 4-15 VDC 5 Amps 48-530 VAC
DRA1-CXE380D5R 15-32 VDC 5 Amps 48-530 VAC
DRA1-CX380D5 4-15 VDC 5 Amps 48-530 VAC
DRA1-CXE380D5 15-32 VDC 5 Amps 48-530 VAC
DRA1-CX480D5R 4-15 VDC 5 Amps 48-660 VAC
DRA1-CXE480D5R 15-32 VDC 5 Amps 48-660 VAC
DRA1-CX480D5 4-15 VDC 5 Amps 48-660 VAC
DRA1-CXE480D5 15-32 VDC 5 Amps 48-660 VAC Spec Document Check Stock
small solid state relay model SSR models:
DRA1-CX24OA5; DRA1-CX24OA5R;
DRA1-CXE24OA5R; DRA1-CXE24OA5;
DRA1-CX24OD5R; DRA1-CXE24OD5R;
DRA1-CX24OD5; DRA1-CXE24OD5;
DRA1-CX38OD5R; DRA1-DRA1-CXE38OD5R;
DRA1-CX38OD5; DRA1-CXE38OD5;
DRA1-CX48OD5R; DRA1-CXE48OD5R;
DRA1-CX48OD5; DRA1-CXE48OD5;
