ACTIVATED CARBON FILTER SPECIFICATIONS
Model |
Flow Rates |
Inlet/Outlet Ports |
||
Service Flow Rates |
Backwash |
|||
Minimum flow (m³/hr) |
Maximum flow (m³/hr) |
Flow (m³/hr) |
||
BM-08-C |
0.4 |
0.7 |
0.6 |
32 mm |
BM-10-C |
0.6 |
1.1 |
1.0 |
32 mm |
BM-14-C |
1.2 |
2.2 |
1.9 |
32 mm |
BM-20-C |
2.5 |
4.5 |
3.9 |
50 mm |
BM-30-C |
5.5 |
10.2 |
8.8 |
50 mm |
BM-36-C |
8.0 |
24.6 |
12.7 |
63 mm |
BM-48-C |
14.1 |
26.0 |
22.6 |
63 mm |
Operating pressure: 200 - 600 kPa
Power supply (automatic units): 220 VAC 50Hz
Temperature range (water temp): 5-35°C
Activated carbon filters are capable of 40-micron effluent water quality under normal operating conditions, although they
should not be used as a sole source of filtration.
sintered activated carbon filter/cto carbon block effective/ sintered activated carbon filter/cto carbon block effective
ACTIVATED CARBON FILTER APPLICATIONS AND BENEFITS
- Food & Beverage Production-Improved taste, clarity and appearance. Chlorine removal.
- Drinking Water-Reduces turbidity, taste and odours as well as chlorine.
- Pretreatment-Ideal for Reverse Osmosis, Deioniser and softener pretreatment
sintered activated carbon filter/cto carbon block effective/ sintered activated carbon filter/cto carbon block effective
Product picture
household carbon block/charcoal water filter /household carbon block/charcoal water filter / household carbon block/charcoal water filter
