Mr-496it4 Touch Screen Transmitter 4CH Bidirectional Auto Frequency Hopping Digital Proportional Remote Controller

Mr-496it4 Touch Screen Transmitter 4CH Bidirectional Auto Frequency Hopping Digital Proportional Remote Controller thumbnail-1
Mr-496it4 Touch Screen Transmitter 4CH Bidirectional Auto Frequency Hopping Digital Proportional Remote Controller photo-1
Negotiable MOQ: 5 Cartons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Use:
Other, control the model car/boat
Place of Origin:
Guangdong, China
Brand Name:
amax
Contact Supplier Request Quote Chat Now
Amax Industrial Group China Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use Other, control the model car/boat
Place of Origin Guangdong, China
Brand Name amax
Model Number mr-496it4

Specifications

Touch screen transmitter
1.Newest auto frequency hopping digital system;
2.With color LCD touch screen

Touch screen transmitter

Item.No.: mr-496it4
Product name: Newest 2.4GHz 4CH Bidirectional Auto Frequency Hopping Digital Proportional Remote Controller with Color LCD Touch Screen (for car/boat model)
Color: black
Weight: 347g
Size: 157*116*258mm
Packaging: color box
Box size: 253*242*75mm
Carton size: 67*39.5*23cm
Quantity: 10pcs/ctn
Model type: car/boat
RF range: 2.4-2.48GHz
Bandwidth: 500KHz
Band: 160
RF power: less than 20 dbm
Sensitivity: 1024
Low voltage warning: yes(less than 3.5V)
DSC port: yes(USB; output: PPM)
ST range: 90
TH range: 45(F: 30;B:15)
Charger port: yes
Power: 3.7V(1200mAh)
ANT length: 26mm

Receiver parameters:
Channels: 4
RF range: 2.40-2.48GHz
Band: 160
RF power: less than 20 dbm
RX sensitivity: -105 dbm
2.4G system: AFHDS2
Code type: GFSK
Power: 4.0-8.4V DC
Weight: 15g
ANT length: 26mm
Size: 35.4*29.6*13mm
Color: black
Certificate: CE0678, FCC
AS-Bus port: yes
Data Acquisition port: yes

Package contents:
4CH 2.4G transmitter*1
4CH 2.4G receiver*1
Serial bus receiver*1
Rotating speed acquisition module*1
Temperature acquisition module*1
Outer voltage acquisition module*1
Pen*1
Hand lever*1
Micro USB cable*1
Adapter/standard USB cable/charger*1(optional)
Servo*1(optional)
Lithium battery*1
User manual*1

Product descriptions:
mr-496it4 adopts the second generation auto frequency hopping digital system, by which transmitter can receive some related information from receiver, such as voltage, temperature, speed and other details. It is the key point that you can get hold of the receiver’s working conditions at all times. Besides, the color LCD touch screen makes it easy to set the relevant parameters.

Selling points:
1.Newest auto frequency hopping digital system;
2.With color LCD touch screen;
3.Receive information from receiver;
4.With lithium battery/both-way data lines.
