Brightness Updated 10R 280W Beam Moving Head
Product's Details:
Source
Lamp: 10r 280 W
Lamp Life Expectancy: Standard mode (280 W) - 2.000 hrs
Control: open the lamp and reset, including delaying function
Ballast: Electronic
Optical System
Light Output:
Spot mode: 64,200 lx @ 3m distance
Spot mode: 8760 lx @ 20m distance
Dichroic glass reflector integrated with the lamp for maximising the light efficiency
Zoom range: 2.5°-10° beam application; 5° – 20° spot application
Electrical Specification
Power supply: Electronic auto-ranging
Input voltage range: 100–240 V, 50/60 Hz
Power consumption: 470 W at 230 V / 50 Hz
Mechanical Specification
Height: 589 mm
Width: 365 mm
Depth: 385 mm
Weight: 19kg
Fixation option: Pan/Tilt-lock mechanism
Control and Programming
Control: Standard DMX-512, Sound active, auto and master/slave modes
Control channels: 24, 16
Stand-alone operation
Motor: 3-phase motor
Data in/out: Locking 3-pin & 5-pin XLR
Power input: Neutrik PowerCon
Built-in analyser for easy fault finding
Electromechanical Effects
Colour wheel: 13 dichroic filters + white
Rotating Gobo wheel: 9 rotating, indexable glass gobos + open
Static Gobo wheel: 14 gobos + open
Prism 1: 8-facet circular prism rotating in both directions at different speeds
Prism 2: 6-facet linear prism rotating in both directions at different speeds
Frost effect: Separate, variable
Dimmer/Shutter: Full range dimming and variable strobe effect
Motorized zoom and focus
Pan: 540°
Tilt: 270°
DMX Channels:
24 channels or 16 channels are available:
Mode 1 |
Mode 2 |
Function |
1 |
1 |
Pan |
2 |
* |
Pan Fine |
3 |
2 |
Tilt |
4 |
* |
Tilt Fine |
5 |
3 |
Pan / Tilt Speed |
6 |
4 |
Macro Function |
7 |
5 |
Color |
8 |
* |
Empty / No Function |
9 |
6 |
Empty / No Function |
10 |
7 |
Fixed Gobo |
11 |
8 |
Rotating Gobo |
12 |
9 |
Gobo Wheel Rotating |
13 |
* |
Empty / No Function |
14 |
10 |
Prism |
15 |
11 |
Prism Rotating |
16 |
12 |
Frost |
17 |
13 |
Zoom |
18 |
* |
Zoom Fine |
19 |
14 |
Focus |
20 |
* |
Empty / No Function |
21 |
* |
Empty / No Function |
22 |
15 |
Strobe |
23 |
16 |
Dimmer |
24 |
* |
Empty / No Function |
carton: one piece of beam light machine for one carton.
fly case: 1/ 2piece/pieces for fly case
shipping:3-8 days after received the payment.
1: If have any problems ,can send it back our company to maintain the machine.
2:u can have our one year warranty.
3if u are not familiar in using our product, we are glad to explain how to use it.
Guangzhou Xiao long photoelectronic Co. ltd. it's a comprehansive manufacturing and trading company, Which is specialized in producing all kinds of stage lighting. We are famous for excellent quality & competitive prices. terricfic after-sales services,safe package and prompt dilivery.
If have any questions, plz kindly contact us.
