ZP series of rotary tables
ZP Series of Rotary Tables ,are widely used to rotate drill equipment and hold the weight of pipes in well .
The technology parameter:
Model No. |
ZP175 |
ZP205 |
Open dia. Mm(in) |
444.5(17 1/2) |
520.7(20 1/2) |
Max. static load (KN) |
2700 |
3150 |
Max. working torque N.m |
13729 |
22555 |
|
Distance between rotary table and chain wheel interal gear axle mm(in) |
1118(44) |
1353(53 1/4) |
Gear ratio |
3.75 |
3.22 |
Max. speed r/min |
300 |
300 |
Input axle centre hight mm |
260.4 |
318 |
Overall dim. mm (L*W*H) |
1972*1372*566 |
2266*1475*704 |
Net weight Kg |
4172 |
5662 |
Model No. |
ZP275 |
ZP375 |
Open dia. Mm(in) |
698.5(27 1/2) |
952.5(37 1/2) |
Max. static load (KN) |
4500 |
5850 |
Max. working torque N.m |
27459 |
32362 |
|
Distance between rotary table and chain wheel interal gear axle mm(in) |
1353(53 1/4) |
1353(53 1/4) |
Gear ratio |
3.67 |
3.56 |
Max. speed r/min |
300 |
300 |
Input axle centre hight mm |
330 |
330 |
Overall dim. mm (L*W*H) |
2392*1670*685 |
2468*1810*718 |
Net weight Kg |
6122 |
7970 |
