Help CenterQ32 Crawler Tumblast Apron Rubber Belt Shot Blasting Machine
Related Products
-
1 High Quality Q326 Tumble Belt Type Wheel Blasting MachineUS$ 2,500 - 60,000MOQ: 1 Set -
1 ISO9001 High Quality Q326 Shot Blasting MachineUS$ 2,500 - 60,000MOQ: 1 Set
-
Q32 Crawler Type Shot Polishing Machine, Rust Stripping Cleaning SandblasterUS$ 3,000 - 50,000MOQ: 1 Set
-
02 Rubber Belt Track Sandblaster, Crawler Shot Blast Cleaning EquipmentUS$ 3,000 - 50,000MOQ: 1 Set
-
02 Dustfree Buffing Crawler Type Shot Blaster, Sandblasting MachineUS$ 3,000 - 50,000MOQ: 1 Set
Apron shot blasting machine
1.The efficient & rugged design of tumble blasting machine increase production, improves quality and reduces fettling cost,
saves labour, spaces, saves power, cuts tooling costs & reduces rejection.
2.The tumble blasting machine is available with rub conveyor or Steel Conveyor. Rugged one piece cast, hardened and
stress relieved chain link gives long life.
3.The Machine is suitable for shot blasting components like valve bodies, Cylinder head, and tractor components. The fast
action of shot blasting removes every trace of sand, scale, write down to virgin metal.
4.There by lengthen tool life, speeding up machining, simplifying inspection, improving appearance. It saves power, labour
and quick return on original investment.
5.Q32 Series Tumble Belt Type Shot Blasting Machine has the advantages of advanced design,reasonable structure small
energy consumption and high efficiency.
Technique parameter
| Type | Q326 | Q3210 | QR3210 | Q3220 |
| Productivity(t/h) | 0.6-1.2 | 3-5 | 2-2.5 | 4-5 |
| Feeding amount(kg) | 200 | 800 | 600 | 1200 |
| Maximum weight of workpiece(kg) | 10 | 150 | 30 | 50 |
| Diameter of end disk(mm) | Φ650 | Φ1000 | Φ1000 | Φ1000 |
| Effective volume(m³) | 0.15 | 0.4 | 0.3 | 0.6 |
| Abrasive flow rate(kg/min) | 120 | 250 | 250 | 2*250 |
| Workpiece speed(m³/h) | 2000 | 6000 | 3500 | 8000 |
| Power consumption(kw) | 12.6 | 32.6 | 24.3 | 53 |
| Out line dimention(mm) | 1500*1880*3900 | 3644*2926*5856 | 3976*2600*4768 | 7200*3500*5800 |
Q326
Q3210
About us
Qingdao Rovan Machinery Co.,Ltd was established in 2001, Asia's largest shot blasting machine supplier, do foreign trade
export for ten years,mainly produces shot blasting machine, shot peening equipment, resin sand equipment, sand plant
equipment, dust collector and conditioning equipment, V law molding line etc.
Trade Terms:
1. Payment:
(1)Telegraphic Transfer(30% advance payment, balance before shipment).
(2)Telegraphic Transfer(30% advance payment, balance against copy of documents).
(3)Letter of Credit: at sight.
2. Lead Time: 2 weeks after confirmed order
3. Delivery way: by sea
Application:
surface treatment
machined part
style design
Service:
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available. UEM&UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory : We are manufacturer, specializing in producing all kinds of machinery for more than 20 years,
competitive with good quantity.
7. Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is
usually paid by your side, the charges will be rebounded when we have formal order.
8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products
to be finished in high quality and stable feature. Welcome to contact us or visit our company.
If you want to buy shot blasting machine, could you tell me the answers as follow?Please indicate the following details:
1) What kind of workpiece will you clean? Material?2) The size of it, length, width and height of maximum workpiece? Length, width and height of minimum workpiece?
3) How heavy is each workpiece? Especially the weight of maximum workpiece?4) How many tons will you clean for each month or each day?
After getting your informations, the detailed technical parameters will be sent to you for your reference. Note:As we are an
integrated company, we sell our products direct to customers without any extra agent charges. Hence, our price is relatively
lower than others. Moreover, we are using the most advanced equipment and technology in order to produce high quality
and more professional.
