Specifications
-Manufacture, can be customized-Rated Voltage:450/750V
-IEC ISO CCC
-Full ranges of size
high quality H05VV-F pvc wire aluminum conductor electrical power cable wire
1.Application : This cable is suitable for fixed distribution lines and electrical facilities for agricultural using able to be buried underground for A/C rated Voltage 450/750V and below.
2.Product characteristics: Max continuous working temperature of conductor should not exceeds 70 oC. Surrouding temperature of laying should not be less than 0 oC.
3.Model and descriptions:
Model |
Description |
NLYV |
Agricultural buried underground, aluminum core,PE insulated PVC sheathed wire. |
NLYV-H |
Agricultural buried underground, cold resistant, aluminum core, PE insulated , PVC sheathed wire. |
NLYY |
Agricultural buried underground, aluminum core, PE insulated, black PVC sheathed wire. |
NLVV |
Agricultural buried underground, aluminum core, PVC insulated, PVC sheathed wire. |
4.Specification
|
Cross-section (mm²) |
No.dia/core (mm) |
Insulation thickness (mm) |
Sheath thickness (mm) |
Conductor resistance at 20 oC |
4 |
1/2.25 |
0.8 |
1.2 |
7.39 |
6 |
1/2.76 |
0.8 |
1.2 |
4.91 |
10 |
7/1.35 |
1.0 |
1.4 |
3.08 |
16 |
7/1.70 |
1.0 |
1.4 |
1.91 |
25 |
7/2.14 |
1.2 |
1.4 |
1.20 |
35 |
7/2.52 |
1.2 |
1.6 |
0.868 |
50 |
19/1.78 |
1.4 |
1.6 |
0.641 |
70 |
19/2.14 |
1.4 |
1.6 |
0.443 |
95 |
19/2.52 |
1.6 |
2.0 |
0.320 |
