140Kw JiChai Chinese Gas Operated Electric Generator

Name: 140Kw JiChai Chinese Gas Operated Electric Generator
Brand: Jichai
SKU: 109823853

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

Jichai

Model Number:

140GFTA1

Evangel (Shanghai) Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Shenzhen Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name Jichai

Model Number 140GFTA1

Output Type AC Three Phase

Speed 1500RPM

Frequency 50HZ

Rated Power 40Kw

Rated Voltage 400V

Rated Current 72A

Specifications

140Kw JiChai Chinese Gas Operated Electric Generator

Product: 140Kw JiChai Chinese Gas Operated Electric Generator

3412T Natural Gas Generator

Rated Power: 24-200Kw

Power Supply Mode: Three phase four line

Rated Frequency: 50Hz

Rated rpm: 1500r/min

Starting mode: 24DC Starting

Generator	Genset Model	GFZ10~GFZ500
	Rated Frequency	50HZ
	Power Factor	0.8
	Rated Voltage	400/230V
	Rated Power (KW/KVA)	10/12.5~500/625
	Standby Power (KW/KVA)	11/13.75~550/687.5
	Rated current (A)	18~900
	Phase/Wire	3 Phase, 4 Wire
	Overall Size (mm)	1450×700×1100~4820×2040×2780
	Weight (kg)	470~12000
Gas Engine	Model	YD480, 2100Q, 4100Q, 4102Q, 4105Q, 6105Q,6113Q, 6135Q, 6140Q, WD615ZQ, 12V135Q, 12V138Q, 12V135ZQ, 12V138ZQ, 12V190ZQ
	Brand	Weifang/Steyr, China
	Type	4-stroke, Muilti-cylinder, in-liner
	Rated Power (kw)	14~550
	No.of Cylinder	4, 6, 12
	Bore×Stroke (mm)	80×90, 100 × 115, 190×210
	Gas Consumption (m3/kw.h)	0.36
	Oil Consumption (g/kw.h)	2
	Cooling Type	Closed water cooling
	Speed Governing Mode	ESC
	Starting Mode	Electric
Alternator	Model	BCI164C, BCI184F, BCI184F, BCI184H, UCI224F, UCI224G, UCI274G, UCI274H, HC1444D, HC1444E, HCI544FS
	Prime Power (KW/KVA)	10/12.5~500/625
	Voltage Regulation	≤±1
	Excitation Type	Brushless
	Insulation Class	H
