Insulating Varnish, Insulation Varnish, Fast Dry Epoxy Dipping Resin R-303

Name: Insulating Varnish, Insulation Varnish, Fast Dry Epoxy Dipping Resin R-303
Brand: Rota
SKU: 109945025

Insulating Varnish, Insulation Varnish, Fast Dry Epoxy Dipping Resin R-303 thumbnail-1

Insulating Varnish, Insulation Varnish, Fast Dry Epoxy Dipping Resin R-303 photo-1

US$ 2.95 - 4.35 MOQ: 100 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Main Raw Material:

Epoxy

Usage:

Appliance Paint, Electrical Insulating Varnish

Contact Supplier Request Quote Chat Now

Jiaxing Rota-Ropa Insulating Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Main Raw Material Epoxy

Usage Appliance Paint, Electrical Insulating Varnish

Application Method Brush

State Liquid Coating

Brand Name Rota

Model Number R-303

Brief Introduction

R-303 is a one-component dipping resin which is formed by epoxy resin, curing agent and thinner.It’s heat-resistant grade is B (130°C). R-303 corresponds the RoHS environmental protection requirement.

Features

Convenient to use, low cost, good manufacturability, bright film, excellent mechanical strength and insulating property.

Application

This paint is fit for the continuous dipping technology, fast-dry dipping insulating operate and VPI process of small-scale stator coil, like fan motor, electric tool motor, air-condition motor and water pump motor etc.

Qualification (as the Q/R 101-2010 company standard)

No.	Test Item	Test Method	Unit	Value
1	Appearance	Test Tube	-	Reddish brown uniform liquid, no mechanical admixture
2	Viscosity	4#cup, 23±1°C	s	11-14
3	Drying time	130±2°C	min	≤30
4	Curing in thick layer	-		No less than S1U1I4.2
5	Resin effect	Enameled wire	H	≥1H
6	Power Frequency Electric Strength	Normalcy	MV/m	≥70
6	Power Frequency Electric Strength	After immersion in water	MV/m	≥50
5	Volume Resistivity	Normalcy	Ω·m	≥1×10¹²
		130°C		≥1×10⁷
		After immersion in water		≥1×10¹¹
6	Pot Life	no gel, below 30°C	d	≥10

Usage

1.Continuous immersion process

1.1 Common technological process:

Start	preheat	cool	immersion	drain	bake	off
rhythm	2	2	1	2	13-17

1.2 Technology parameter:

rhythm time	3-7 minutes
preheating temperature	125-135 °C
gel temperature	125-135 °C
curing temperature	130-140 °C

1.3 Attentions:

(1) R-303’s viscosity is 10-14s when uses, if the viscosity is too large, it should be diluted by our special 303-X thinner.

(2) Capping the paint tank and immersion tank when do not work.

(3) Paint tank and paint line should be cleaned regularly (1-3 months once), with the 100-150 mesh filter screen to remove the iron filings, coat of paint, dirt and other impurities.

2. VPI process (for compound vacuum impregnation drying machinery )

2.1 Preheat: Put the unit in immersion tank, rise temperature up to 50-60°C and keep for 30 mins, vacuumize to -0.09MPa and keep 2-5 mins then input resin.

2.2 Vacuum impregnation: Close the vacuum valve, input the resin at least 50mm above the unit, keep the vacuum of -0.08MPa for 3-5 mins.

2.3 Relieve vacuum of immersion tank, then vacuumize for paint tank, and return the resin.

2.4 Drain unit for 30-60 mins.

2.5 Clean: Input thinner into the bottom of tank with pump and keep 5 mins.

2.6 Bake at 120-130°C for 2 hours until dry.

Established in 1992, Rota Group is one of the most professional manufacturers of impregnating varnish, mica tape, potting resin and embedding resin in China. Most products have been approved by ISO9001, 14000, UL, TUV, FDA, RoHS and REACH, widely used in high-voltage motors, wires and cables, household appliances, industrial pumps, and metallurgy equipments etc. We win the trust of the majority of well-known manufactures, like BOSCH, BLACK & DECKER, Fujitsu, Shibaura, REGAL, Siemens, EPCOS, N.P.V. and so on.

Professional quality, creating value for customers. Rota Group lead in the aspects of industry scale, product technology and innovation capacity, we will provide quality products and professional services for you. Welcome you!
