Home > Chemicals > Paint & Coating > Building Coating > Impregnating Varnish Insulation Varnish R-1140-3

Impregnating Varnish Insulation Varnish R-1140-3

Name: Impregnating Varnish Insulation Varnish R-1140-3
Brand: rongtai
SKU: 109945095

Impregnating Varnish Insulation Varnish R-1140-3 thumbnail-1

Impregnating Varnish Insulation Varnish R-1140-3 thumbnail-2

Impregnating Varnish Insulation Varnish R-1140-3 thumbnail-3

Impregnating Varnish Insulation Varnish R-1140-3 thumbnail-4

Impregnating Varnish Insulation Varnish R-1140-3 thumbnail-5

Impregnating Varnish Insulation Varnish R-1140-3 photo-1

Impregnating Varnish Insulation Varnish R-1140-3 photo-2

Impregnating Varnish Insulation Varnish R-1140-3 photo-3

Impregnating Varnish Insulation Varnish R-1140-3 photo-4

Impregnating Varnish Insulation Varnish R-1140-3 photo-5

US$ 3.45 - 5.65 MOQ: 100 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Main Raw Material:

Other, unsaturated polyester

Usage:

Electrical Insulating Varnish

Contact Supplier Request Quote Chat Now

Jiaxing Rota-Ropa Insulating Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Main Raw Material Other, unsaturated polyester

Usage Electrical Insulating Varnish

Application Method Other, impregnation

State Liquid Coating

Brand Name rongtai

Model Number R-1140-3

Introduction

R-1140-3 fast curing solvent-free impregnating resin is made from unsaturated polyester resin, curing agent and thinner etc. It presents in one-component form and with thermal class F. It has gained UL certification (No.: E227128) and comply with the RoHS environmental requirements.

R-1140-3 is widely used and suitable for impregnation of small types of motors and apparatus coils, recommend for Y2 series motor, water pump motor, electric tool motors, and air-condition motor etc. It can be used by fast drying immersion, continuous immersion and VPI method of application.

Qualification

No.	Test Item	Test Method	Unit	Value
1	Appearance	Test Tube	-	Red brown transparent liquid, no mechanical admixture
2	Viscosity	4#cup, 23±1°C	s	20-50
3	Gel time	130±2°C	min	3-8
4	Curing in thick layer	2h/130±2°C	-	No worse than S1U1I3,2,
4	Power Frequency Electric Strength	Normalcy	MV/m	≥20
5	Volume Resistivity	Normalcy	Ω·m	≥1×10¹²
		After immersion in water		≥1×10¹¹
		155°C		≥1×10⁷

Usage

1. Fast drying impregnation process

1.1 Preheat unit for 1-3 hours at 100-120°C.

1.2 Allow unit to cool to 60°C before dipping into varnish, dip unit in varnish for 2-15 mins until basically no bubble.

1.3 Drain unit for 30-60 mins.

1.4 Bake unit for 2-4 hours at 120-130°C.

2. Continuous immersion process

Flow chart

Start	preheat	cool	immersion		Drain	cure	off
rhythm	2	2	1		2	13-17
(1)rhythm time				3-7 mins
(2)preheating temperature				125-135°C
(3)gel temperature				125-135°C
(4)curing temperature				130-140°C

3. Vacuum impregnation process

3.1 Preheat: Rise temperature up to 50-60°C and keep for 30 mins, vacuumize above -0.09MPa and keep 2-5 mins then input resin.

3.2 Vacuum impregnation: Close the vacuum valve, input the resin at least 50mm above the unit, keep the vacuum of -0.08MPa for 3-5 mins.

3.3 Returning resin.

3.4 Drain unit for 30-60 mins.

3.5 Clean: Input thinner into the bottom of tank with pump and keep 5 mins.

3.6 Bake at 120-130°C for 2 hours.

Established in 1992, Rota Group is one of the most professional manufacturers of impregnating varnish, mica tape, potting resin and embedding resin in China. Most products have been approved by ISO9001, 14000, UL, TUV, FDA, RoHS and REACH, widely used in high-voltage motors, wires and cables, household appliances, industrial pumps, and metallurgy equipments etc. We win the trust of the majority of well-known manufactures, like BOSCH, BLACK & DECKER, Fujitsu, Shibaura, REGAL, Siemens, EPCOS, N.P.V. and so on.

Professional quality, creating value for customers. Rota Group lead in the aspects of industry scale, product technology and innovation capacity, we will provide quality products and professional services for you. Welcome you!
