Home > Chemicals > Silicone & Silicone Products > Epoxy Resin Potting R-381-3(white)

Epoxy Resin Potting R-381-3(white)

Name: Epoxy Resin Potting R-381-3(white)
Brand: Rota
SKU: 109945589

Epoxy Resin Potting R-381-3(white) thumbnail-1

Epoxy Resin Potting R-381-3(white) photo-1

US$ 3.08 - 3.85 MOQ: 100 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Classification:

Double Components Adhesives

Main Raw Material:

Epoxy

Contact Supplier Request Quote Chat Now

Jiaxing Rota-Ropa Insulating Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Classification Double Components Adhesives

Main Raw Material Epoxy

Usage Other, transformer,capacitor

Brand Name Rota

Model Number R-381-3(white)

epoxy resin potting R-381-3(white)

1.made from epoxy resin, hardener and filler presented in two-component form.

2. cures at room temperature.

3. has good fire resistance property and has gained RoHS certification, UL certification (E229550) and UL insulation system certification (E242776).

4.used for embedding, casting and potting for electronic components, motor and apparatus coils. Such as: small transformer and instrument transformer coils, capacitor, ignition coils of autocycle and auto etc.

5.Technical Data

Properties	Testing condition	Unit	Standard values
appearance	Test tube method	-	A white liquid B brown liquid
Viscosity	-	cps	A 15000 cps at 40 B 150 cps at 23
Relative density	Water=1		A 1.62 B 1.20
Gel time	23±2	h	≤10
Hardness		Shore D	75±5
Dielectric strength	At room temperature	MV/m	≥20
Volume resistivity	At room temperature	Ω.m	≥1×10¹³
Volume resistivity	after immersion in water	Ω.m	≥1×10¹²
Pot life	23±2, no gel	h	≥1
Fire resistance	-	-	UL94 V-0

Established in 1992, Rota Group is one of the most professional manufacturers of impregnating varnish, mica tape, potting resin and embedding resin in China. Most products have been approved by ISO9001, 14000, UL, TUV, FDA, RoHS and REACH, widely used in high-voltage motors, wires and cables, household appliances, industrial pumps, and metallurgy equipments etc. We win the trust of the majority of well-known manufactures, like BOSCH, BLACK & DECKER, Fujitsu, Shibaura, REGAL, Siemens, EPCOS, N.P.V. and so on.
