Home > Industrial Equipment & Components > Compressor > Compressor Unit > Home Infilating Compressor

Home Infilating Compressor

Name: Home Infilating Compressor
Brand: Tagore
SKU: 109976511

US$ 40 - 90 MOQ: 20 Pieces

Key Specifications

Get Latest Price

Condition:

New

Type:

Centrifugal

Configuration:

Portable

Contact Supplier Request Quote Chat Now

Ningbo Tagore Machinery Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Centrifugal

Configuration Portable

Power Source AC Power

Lubrication Style Oil-free

Mute Yes

Place of Origin Zhejiang, China

Brand Name Tagore

Model Number TG230T

Voltage 220V/110V 50HZ/60HZ

Dimension(L*W*H) 33*15.5*33 cm

Weight 8.1kg

Certification CE&BV

Warranty one year warranty

After-sales Service Provided No overseas service provided

home infilating compressor

oill-free portable Double Cylinder Piston Airbrush air compressor with Tank

Product Description

Product Name: Cylinder infilating Compressor

Model

TG-230T

Brand

TAGORE

Features

1) Air tank, providing smooth air flow, zero pulse.

2) Twin cylinder, supply high air flow for many airbrushes.

3) Oil free, piston type; No air polluted.

4) With water filter, pressure adjustor and pressure gauge.

5) Double air pressure switch.

Switch 1, low pressure switch, for airbrush purpose.

Switch 2, high pressure switch, for other high pressure air tools.

6) Auto release air pressure function, start without any pressure, prolong the motor life.

7) Thermally protected inside.

8) Safety protect devices for air tank.

9) Can operate with small air nailed tools, spray gun

10) low noise,47db

Specifications

Specifications:

Power: 1/4 HP

Speed: 1450/1700 r.p.m

Air output per min./liters: 35~40L/min

Double switch:

Switch 1: Start at 2.8Bar, auto stop at 4Bar

Switch 1: Max pressure at 6 Bar.

Working pressure: 0~6 bar

Air tank: 3.5L

Weight: 7.2KG

Dimension: 365X162X317mm

Suitable for all kinds of airbrush.

Package

Qty: 3 PCS/ CTN
Net weight:21.6KG
Gross weight: 23.6KG

Paper Carton Dimensions (cm): 48X38.5X34

Certificate

Ideally suited for airbrush studios & workshops!

Powerful: 1/6 Horsepower; Delivers a high air volume (1.6 cfm) and up to 46 liters/minute of airflow, allowing it to easily operate 2 airbrushes
Portable: Lightweight, compact and easy to carry with the built in handle
Precise Air Adjustment: True diaphragm pressure regulator with gauge and water trap filter that provides precise adjustment of airflow and will ensure clean, dry air
Double Switch for Automatic On/Off Shutoff:Constant Pressure and Zero Pulsation: Air is drawn from the large air storage tank providing you a constant regulated pressure. There's zero pulsation because air is drawn from the tank which eliminates any pulsation effect from the pistons
- First Switch Position is Preset for automatic turn on when air tank pressure is below 43 PSI and Preset for automatic turn off when air tank reaches 57 PSI. The reduced running time means there will less motor wear and less heat-related moisture enabling a longer compressor life.
- Second Switch Position allows air tank to reach the maximum pressure of 85 PSI then the Automatic Safety Release Valve releases the excess pressure
"Air-On-Demand": Designed to work only when you do, produces full-capacity air on demand. Automatically shuts off when not is use
Thermally Protected: Automatically turns itself off if the unit becomes over heated.

More optional for air compressor Data sheet:

Model	Power	Speed/min		Auto stop		Auto start		Air flow	Tank
Model	HP	50HZ	60HZ	Bar	Psi	Bar	Psi	L/min	L
TG230	1/4	1450	1700	4	57	3	43	30-35	/
TG230C	1/4	1450	1700	4	57	3	43	30-35	/
TG230T	1/4	1450	1700	4	57	3	43	30-35	4
TG230TC	1/4	1450	1700	4	57	3	43	30-35	4

Model	Max pressure		N.W.	Unit dimension	Carton dimension	Pcs/ctn	Weight
Model	Bar	Psi	Kg	LWH	LWH	Pcs/ctn	N.w/G.w
TG230	/	/	5.5	32×13.5×20.5	67×38.5×26	4	22/25
TG230C	/	/	6.8	32×13.5×22	67×38.5×26	4	27.2/30.2
TG230T	6	86	8.1	33×15.5×33	50×34.5×36	3	24.3/27.3
TG230TC	6	86	13	33×17.5×38.5	50×35×43	3	39/42

Warranty:

All of our products comes with one year warranty from the date of purchase. Any products found to be defective in material, workmanship or worn to be not usable which will be repaired or replaced at our expense. This warranty does not cover any damage caused by negligence, accident, misuse or units which have been abused or altered in any way. No other warranty is expressed or implied.

Fore more choice and detailed specification, please visit our website and download our E-catalogue. If any question, please feel free to contact us! We willl reply you immediately!
