Help CenterManufacturing Toroidal Transformer BOD-6000VA With CE ROHS Certification 220VAC to 110VAC 24VAC
Related Products
-
Manufacturing Toroidal Transformer BOD-8000VA With CE ROHS Certification 220VAC to 110VAC 24VACUS$ 5 - 1,000MOQ: 1 Set -
Manufacturing Toroidal Transformer BOD-6300VA With CE ROHS Certification 220VAC to 110VAC 24VACUS$ 5 - 1,000MOQ: 1 Set
-
Manufacturing Toroidal Transformer BOD-5000VA With CE ROHS Certification 220VAC to 110VAC 24VACUS$ 5 - 1,000MOQ: 1 Set
-
Manufacturing Toroidal Transformer BOD-3150VA With CE ROHS Certification 220VAC to 110VAC 24VACUS$ 5 - 1,000MOQ: 1 Set
-
100kva Distribution TransformerUS$ 100 - 10,000MOQ: 1 Set
We are professional manufactory of power distribution transformer, isolation control transformer , auto transformer, toroidal transformer,voltage regulater, stabilizer etc..
Specifications
1 the product through ISO certification
2 magnetic flux leakage, less little interference
3 can be customized. OEM
4 high efficient/low magnetic flux leakage/low noise/low temperature, CE
Feature
It is producted by 0.27 mm or 0.30 mm high quality cold-rolled orientation silicon materials which is low iron loss and high magnetic, the advantages of our products are small size, low temperature, magnetic flux leakage small, installation easy.
High efficient
It is product by high quality material and the type is compact. It can narrow the gap between the coil and the core. So the efficiency is above 90%.
Low magnetic flux leakage
The gap between core and coil is small and the coil is uniformly.
Low noise and low temperature
Due to the high quality materil and the coil is uniformly, the resistance loss and the fever is very low.
Application
Toroidal transformer is widely used in the area of the power transportation and the tranform of voltage and current. It is widely used in the power technology and electronic area. Such as autotransformer, isolation transformer and lighting transformer etc. It also has special application,such as mutual inductor. We can produce the transformer as the guests’ requirements.
Power (VA) |
Size | Weight (kg) | Chasiss size | Gland | Screw | |
| H(mm) | D(mm) | L×W(mm) | Mounting hole(mm) | mm | ||
| 20 | 32 | 70 | 0.5 | 80×80 | 6.5 | M6 |
| 30 | 30 | 73 | 0.6 | 80×80 | 6.5 | M6 |
| 50 | 30 | 80 | 0.85 | 90×90 | 6.5 | M6 |
| 80 | 35 | 85 | 1.1 | 100×100 | 6.5 | M6 |
| 100 | 40 | 90 | 1.32 | 100×100 | 8.5 | M8 |
| 150 | 45 | 95 | 1.4 | 100×100 | 8.5 | M8 |
| 200 | 50 | 105 | 2.4 | 110×110 | 8.5 | M8 |
| 250 | 52 |
110 | 2.7 | 110×110 | 8.5 | M8 |
| 300 | 55 | 110 | 2.9 | 110×110 | 8.5 | M8 |
| 350 | 60 | 115 | 3.2 | 125×125 | 8.5 | M8 |
| 400 | 65 | 120 | 3.5 | 125×125 | 8.5 | M8 |
| 450 | 65 | 120 | 3.8 | 125×125 | 8.5 | M8 |
| 500 | 68 | 120 | 4.2 | 125×125 | 8.5 | M8 |
| 600 | 70 | 140 | 5.3 | 150×150 | 8.5 | M8 |
| 700 | 70 | 147 | 5.6 | 150×150 | 8.5 | M8 |
| 800 | 70 | 150 | 6.2 | 150×150 | 8.5 | M8 |
| 1000 | 75 | 165 | 7.6 | 180×180 | 8.5 | M8 |
| 1200 | 78 | 170 | 8.5 | 180×180 | 8.5 | M8 |
| 1500 | 80 | 175 | 9.7 | 180×180 | 10.5 | M10 |
| 1800 | 83 | 190 | 12.5 | 200×200 | 10.5 | M10 |
| 2000 | 88 | 200 | 13.5 | 200×200 | 10.5 | M10 |
| 2500 | 92 | 205 | 14.8 | 200×200 | 10.5 | M10 |
| 3000 | 98 | 220 | 16.5 | 230×230 | 11.5 | M10 |
| 5000 | 110 | 235 | 20.5 | 245×245 | 12.5 | M10 |
