CCTV 3D Joystick Control Network Keyboard for Security

CCTV 3D Joystick Control Network Keyboard for Security thumbnail-1
CCTV 3D Joystick Control Network Keyboard for Security photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
K&D
Model Number:
KDW-DN507
Contact Supplier Request Quote Chat Now
Shenzhen Guowei Security Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name K&D
Model Number KDW-DN507

Specifications

> Three Dimensional Joystick Control of PTZ Functions
> Preset Position, Auto Scan, Auto Pan, Auto Tour & Pattern Control

CCTV 3D joystick control Network Keyboard  for security



> Keyboard to Control:
—Standalone DVR
—High Speed Dome
—Network High Speed Dome
—Central Management Platform
—Network Video Server
> RS232, RS485 & Network Connections
> Three Dimensional Joystick Control of PTZ Functions
> Preset Position, Auto Scan, Auto Pan, Auto Tour & Pattern Control
> Auxiliary Functions
> On-Screen Menu & User Operation Procedure Tips





Model

KDW-DN507

General

Keyboard Keypanel

Electromechanical

Joystick

3-axis, vector-solving, with twisting, return to-center head

Keyboard Connector

RJ-45, RS232, RS485

Keyboard Communication

Direct Mode, Network Mode

Direct Mode

Interface: RS232/RS485
DVR Protocol: DH1/DH2
Dome Protocol: DH-SD/PELCO-D/PELCO-P/PELCO-D1/PELCO-P1

Network Mode

Interface: RJ45
DVR/Network Dome:
IP Address/Port/Protocol

Display

LCD, 84mm x 31mm

Environmental

Power Supply

Power adapter, input 100V~240V 50Hz / 60Hz,output DC12V/1000mA

Power Consumption

5W

Working Temperature

-10°C~+55°C

Working Humidity

10%~90%

Atmosphere Pressure

86kpa~106kpa

Dimension

320mmx190mmx50mm (W×D×H) (height: 100mm including joystick)

Weight

2.5KG









 CCTV 3D joystick control Network Keyboard for security
