High Temperature Aging Test equipment
application:
High temperature aging test machine is used to test big samples, such as electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries
High Temperature Aging Test equipment features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips and plane handle with no reaction.
2. Rectangular viewing window for the products under test, with interior light.
3. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot.
4. French Tecumsehis used for the circulation system of compressor, capable of removing the lubricant between the condensation pipes and capillaries. Environment friendly coolant (R23, R404A).
5. LCD display screen, capable of displaying the measured value as well as the set value and time.
6. The control unit has the functions of multiples segment program editing, and of temperature ramp control.
7. Casters are provided for ease of mobility, with strong positioning screws.
High Temperature Aging Test equipment technical parameters:
Model |
TAR-volume |
Interior Dimensions(cm) |
Can be customed |
Temperature Range |
RT+10°C to 80°C(80°C to 150°C is optional) |
Indication Resolution / Distribution Uniformity of Temperature |
0.1°C /±2.5°C; |
Control Accuracy of Temperature |
±0.5°C; |
Temperature Rising Velocity |
Approx. 0.1 to 3.0 °C/min |
Cooling System |
Refrigeration by compressor, according to customer’s requirements |
Protection Devices |
Fuse free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over temperature protection switch, fuses, fault warning system |
Optional Accessories |
Enter ramp , Recorder |
Compressor |
French Tecumseh , Germany Bizer |
Power |
AC 380V,50/60HZ |
Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.
Short introduction about ASLi factory:
We are a long history testing equipment manufacturer, in the past 25 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine. High Temperature Aging Test equipment is our star products, and we had obtained the CE certification for this machine.
More High Temperature Aging Test equipment pictures:
